Shanghai Changlei Machinery Complete Equipments Co., Ltd. >> Cone Crusher (PYD)

Cone Crusher (PYD)

Name: Cone Crusher (PYD)
Brand: china-manufacturer-directory.com
SKU: 677775445
Availability: InStock
Rating: 4.9 (103 reviews)

Supplier:	Shanghai Changlei Machinery Complete Equipments Co., Ltd.
Price:	Negotiable
Min Order:	1set
Quantity::
Trade Terms:	by Sea

Product Specifications

Prod Model:	PYD
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Cone Crusher
Color:	Color: as You Request
Power:	160kw
Capacity:	280-480 Tph
Advantage:	Hydraulic Control System
Installation:	Under Engineer Guide
Weight:	10-20 T
Production Efficiency:	High
Stone Shape:	Regular Shape
Application:	Aggregates, Ore, Quarry, Mining, Crush...
Tongs' Features:	Dedicated Tongs
Finished Surface:	Cut Off Tool
Cutter Material:	High-Speed Steel
Principle:	Planar Motion Culling
Compressive Strength (',For Crushing):	>300MPA
Crushing Style:	Grinding and Impact

Product Description

The spring safety system of crusher acts as an overloading protection system that allows metal to pass through the crushing chamber so as not to damage the cone crusher. The safety system uses dry oil and water as two kinds of sealed formation to make plaster powder and engine oil separate to make sure reliable performance.

The type of crushing chamber depends upon size of feeding and fineness of crushed product. The standard type (SDY) is applied to medium crushing, the medium type is applied to medium or fine crushing and the short head type is applied to fine crushing.

model	Outside diameter Of crushing cone (mm) (mm)	Max feed size (mm)	The adjusting range of discharger (mm)	Capacity (t/h)	Power (kw)	Weight (t)
PYB600	Φ600	65	12-15	40	30	5
PYD600	Φ600	35	3-13	12-23	30	5.1
PYB900	Φ900	115	15-50	50-90	55	11.2
PYZ900	Φ900	60	5-20	20-65	55	11.2
PYD900	Φ900	40	3-13	15-50	55	11.3
PYB1200	Φ1200	145	20-50	110-168	110	24.7
PYZ1200	Φ1200	100	8-25	42-135	110	25
PYD1200	Φ1200	50	3-15	18-105	110	25.3
PYB1750	Φ1750	215	25-50	280-480	160	50.3
PYZ1750	Φ1750	185	10-30	115-320	160	50.3
PYD1750	Φ1750	85	5-15	75-230	160	50.2
PYB2200	Φ2200	300	30-60	590-1000	280/260	80
PYZ2200	Φ2200	230	10-30	200-580	280/260	80
PYD2200	Φ2200	100	5-16	120-340	280/260	81.4

Shanghai Changlei Machinery Complete Equipments Co., Ltd., is an international-type specialized business which specializes in manufacturing mining crushing machinery, sand processing equipment and industrial milling equipment. Integrated itself with the developing, producing and selling, we devote ourselves in offering our customers the crusher equipment with the highest quality and efficient.

Twenty years involving in this field, Changlei has a wide product coverage in our two producing factories, based in Jiangsu Province and Shanghai, and is also one of the biggest manufacturer for professional wear-resistant materials used in crushers in China. We do supply the wear-resistant components to many crusher equipment factories through which we win the trust and reputation from both our customers and other crushing manufacturers
