Continues Rail Single Platform Train Scale

Product Specifications

Prod Model:	ZGU-100-BDG

Product Description

This rail track scale is suitable for the dynamic weighing of all kinds of wagon. This system consists of non-breaking rail weighing body, PC, weighing software, high accurate load cell, high accurate sampling channels.
Features:
Strong adaptability to the ramp and curves of the track
Control whole weighing optimal accuracy due to advanced microelectronic components and computer data processing technology.
Simple and quick for civil work and installation
Without limitation for the transit speed due to the continues rail
Can realize high speed weighing
The design has the features of standardization, normalization and strong universality
Technical Data
Capacity 18-100t
Weighing Mode Automatical, bi-directional, bogie weighing
Weighing Speed 5-35km/h
Voltage AC220V(-20%~+15%)
Temperature -45 degree~+60degree(outdoor) 0degree~+40degree(indoor)
Relative humidity ≤ 95%(outdoor) ≤ 85%(Indoor)

Function
1. Self-checking, automatically calibration and zero adjustment
2. Automatically weighing whole wagon, bogie weight in front and behind
3. Automatically identify the locomotive, wagon, speed and auotomatically weighing through no switch mode
4. Display the weigh of the wagon under static state
5. Setting and saving the type of wagon, wagon no, consignee, consigner and name of goods and so on
6. Scan, revise, query and statistics
7. Print weighing data in different formats
8. Accumulation and summarizing according to selected projects
9. With anti-thunder device
10. Can configure the automatically identification wagon No system if you need
11. Offer network communication interface to realize the connect with LAN, Station Monitoring system and so on.
