Shenzhen HTS Optoelectronic Technology Co., Ltd. >> Custom Full Color P2.5 Indoor Fixed LED Display

Custom Full Color P2.5 Indoor Fixed LED Display

Name: Custom Full Color P2.5 Indoor Fixed LED Display
Brand: china-manufacturer-directory.com
SKU: 756925765
Availability: InStock
Rating: 4.6 (67 reviews)

Supplier:	Shenzhen HTS Optoelectronic Technology Co., Ltd.
Price:	US $ 4200-4500/Piece
Min Order:	1/Square Meter
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	INPLED-P2.5(3)
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Moudle Size:	160X80mm
Price:	Negotiable
Charactor:	with Cover or Without Cover
Display Type:	LED Video Display
Tube Chip Color:	Full Color
Display Function:	Video Display
Scanning Mode:	1/16 Scan
Certification:	ETL
Pixel Configuration:	1R,1G,1B
Application:	Shopping Guide
IP Rating:	IP43
Pixel Pitch:	2.5
Pixel Density:	160000dots/M²
System Operating Platform:	Win XP/Win7 /Win8/ Win2000

Product Description

Indoor Project 3 in 1SMD LED Display Screen

P2.5

Product description

NO.	Item	Parameter
1	Model	P2.5
2	Pixel pitch	2.5mm
3	Pixel configuration	1R1G1B
4	LED type	SMD2121
5	Module size	160x160mm
6	Module resolution	64x64
7	Cabinet resolution	128x128
8	Cabinet size	320x320mm
9	Density	160000dots/m2
10	Brightness	≥1200nits
11	Scan method	1/16
12	Best view distance	3m
13	Max. power consumption	300W/panel
14	Ave. power consumption	150W/panel
15	Cabinet weight	7 kg
16	Refresh rate	≥960Hz
17	Grey scale	65536 levels
18	Colors	281 billion
19	View angle	Horizontal: 140°, Vertical: 140°
20	Color temperature	6500K
21	Frame frequency	≥60Hz
22	Out of control pixel rate	<1/10000
23	MTBF	>5000 hours
24	Lifespan	50000 hours
25	Control mode	Synchronous display with control PC by DVI
26	Working voltage	AC 100/200v 50-60Hz
27	Control distance	Ethernet cable: 100m, Multi-mode optical fiber: 500m, Singel-mode optical fiber: 20km
28	Operation temperature	-20 to +60
29	Operation Humidity	10% to 80%
30	Protection level	Indoor

Application: Stage Performance, Advertising, Shopping Guide

System Operating Platform: Win XP/Win7 /Win8/ Win2000

Certification: CE, ROHS, UL, CCC, ETL

Features:

1. Seamless of unit joint
2. Intelligence of brilliance control
3. Real and natural color
4. Exquisite and smooth picture
5. Greater Optimal viewing area
6. Stability

Applications:

It is Widely use for shopping malls, entertainment venues, schools, government agencies, trade fair, fair, aiming at the exhibition, press conference, meeting rooms, cinemas, airports, hotels, internal, station waiting area, indoor stadium, and a variety of public facilities and so on.

Packing reference:(Carton , wooden case , flight case)

Shenzhen HTS Optoelectronic Technology Co., Ltd is a Shenzhen-located high-Tech enterprise which specializes in the R&D, manufacturing, salesand serviceof LED display and LED lighting products. Thanksto the human-base management policy, advanced production machines and test equipments as well as rich options of raw material resource, HTS has developed a professionalplatform to become a modern enterprise. According to the demand of the market HTS has developed a Full product range through industry-chained opetatio model and HTS aims to rank. In the front line of the LEDdisplay industry. Of professional designers and software and hardware systems personnel, creative and unique copy talent.

HTS is located in Dalang, Longhua, Baoan District, which enjoys a group of influential experts in LED industry, a professional R&D team and highly-skilled manufacturing staff. It occupies more than 6000 square-meter free-dust and static-proof production area which covers several automated assembling lines, many advanced production machines and optimized testing equipments. Aim to the high level market, HTS insists developing MID and high-end products, serves the customers as the center of our work, strives for survival on the basis of quality, employs the managing idea of searching development by integrity, we manage to win the customers and the market by our sincerest heart, most advanced technology, best-quality products and most satisfactory service.
