Digital Display Electromagnetic Liquid Flow Meter
| Price: |
US $ 600/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
Digital Display Electromagnetic Liquid Flow Meter (A+E 81F)
Highlights--aluminum alloy housing electromagnetic liquid flow meter, good enclosure.--unique 6 layer circuit board design, immune to electromagnetic interference.--fault detective supported like excitation circuit turn-off.--plug & play terminal block--damp-proof sealed sensor treatment--reliable blank pipe inspection Features--large choice of liner materials like F4, PTFE, F46, Fs and rubber.--electric conductivity of medium can be used for detection of product change.--no additional pressure loss.--no moveable parts and long working life.--site digital LCD displays instantaneous flow, accumulative flow, flow rate.
--various output method, like 4-20mA, 0-5V, RS485 and pulse.--compact, split and plug-in types optional.--change the grounding as the third electrode.Specifications| Principle | electromagnetic liquid flow meter |
| Applicable pipe size | DN 15-800 (1/2'' to 31-1/2'') |
| Applicable media | liquid with conductivity > 5 uS / cm |
| Velocity range | 0.2~8 m/s (0.66 to 26.2 ft/s) |
| Accuracy | 0.5%FS, 1.0%FS |
| Process connection | flange, ANSI / GB / JIS, 1.0MPa, 1.6MPa, 4.0MPa, 16MPa optional |
| Processing temperature | -20 to 150°C, according to lining material |
| Ambient condition | -40 to 80°C, relative humidity <95% |
| Power supply | AC220V, 50Hz / DC24V / battery |
| Display | backlight LCD |
| Operation | 4 light touch buttons |
| Signal output | 4-20mA, loading resistance 750Ω, |
| pulse, 0-3kHz, 5V, |
| RS485 |
| Consumption | <8W |
| Cable inlet/outlet | M20*1.5 |
| Protection | transducer IP68, converter IP65 |
| Tube material | carbon steel, stainless steel optional |
| Lining material | PTFE, rubber, polyurethane, F46, Fs optional |
| Electrode material | stainless steel, Hastelloy B, Hastelloy C, Titanium, Tantalum, Platinum optional |
| Grounding | made into a third electrode, same material with electrode |
| Industries | chemical, environmental, metallurgical, pharmaceutical, papermaking, water supply and drainage, etc. |
Company InformationAEAD Technology moves to Chinese first free trade zone --Shanghai Pilot Free Trade Zone in Nov. 2014. That is a milestone for the company development to global market. AEAD Technology is committed to provide the very best support possible. Our customers have unique service needs, and we offer a variety of service options to support them. For any questions, you will either get the answer or have one of our professionals to contact you within 24 hours.
How to contact us?If you are interested in electromagnetic liquid flow meter, please call our office at +86-(0)21-5869 6328.Alternatively, you can send us an email or use the contact form which can be found on the contact page of our website.
| Prod Model: |
A+E81F |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Item: |
Liquid Flow Meter |
| Velocity Range: |
0.2~8 M/S (0.66 to 26.2 Ft / S) |
| Electrode: |
316L, Hc, Hb, Ti, Ta |
| Output: |
4-20mA with Hart, Pulse, RS485 |
| Pressure: |
Max.16MPa |
| Media Temperature: |
Max 180 C (356 F) |
| Ambient Temperature: |
Sensor 80c(176f), Converter 50c(120f) |
| Power Supply: |
220VAC or 24VDC |
| Consumption: |
<8W |
| Grounding: |
S.S, Hc, Ti, Ta, Cu |
| Type: |
Electromagnetic Flow Meter |
| Measuring Principle: |
Electrical Principles |
| Measuring Media: |
Liquid |
| Main Application: |
Corrosive Liquid/Gas |
| Sensor: |
Tube/Flange |
| Accuracy: |
0.5% |
| Size: |
Dn 15-800 (1/2'' to 31-1/2'') |
Shanghai AEAD Technology Co., Ltd is a cooperation of Chinese and German technique which mainly performs in R&D, production and sales.
AEAD Technology was first founded in 2009 in Jiangsu, and established Shanghai Branch in May 18th, 2014. The new Shanghai factory would complete in DEC 2014, located in the Free Trade Zone. Before the business started in 2009, the General Manager Mr. R. H. Liu and Technical Director Mr. S. P. Zong had dedicated in instrumentation for more than 20 years. After 5 years development and achieving good reputation in domestic market, we become a leading manufacture in East China. Now we believe we are ready to overseas users.
The company adopts advanced production line from Germany, and the main products include A+E series products for exporting and A+D products for domestic sales in pressure, temperature, flow, level, calibration and valve which can cater for the needs from domestic and foreign markets. Products are organized and sold under fully dedicated divisions, each staffed with an experienced and highly trained team of dedicated technical sales, applications engineering and customer service support personnel. Products are applied to water treatment, petrochemical, chemicals, machinery, pharmacy, food, mine, metallurgy, etc.
AEAD Technology adheres to the development strategy of Internationalization, Technicalization, Industrialization, which can realize the high-end extension of the products from domestic market to international market. The value chain turns from providing single product to system solution, and the operation expands from linear-oriented to a comprehensive modern enterprise operation including merger and capital operation.
The company has already passed the ISO9001 Quality Management System Certification, ISO14001 Environmental System Certification, and Occupation Health Safety Management System Certification (OHSAS18000).
