DVB-C Qam Modulator DMB-5100

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Mid East,Eastern Asia,Western Europe
Type:	TV Front-end Equipment

Product Description

1.1 Outline

DMB-5100 QAM Modulator is a powerful modulator, integrated with new ideas to meet the complicated market demand. It inputs QPSK signal directly (optional QAM/COFDM) and demodulate it into MPEG TS, then QAM modulate it into RF output; It can obtain MPEG TS from SDH network by DS3 adaptor, then QAM modulate it into RF output; Meanwhile, it supports multiplexing function, multiplexes ASI/SPI with all TS from various connectors, and modulates it into RF output, or output TS directly. DMB-5100 QAM Modulator not only meet the demand of broadcasting business economically and efficiently, but also ensure the promoting of advanced business in the future.

1.2 Features
Comply with ITU-T J. 83
Support various input mode: ASI/SPI, RF(optional QPSK, QAM, COFDM), DS3(optional)
Support ASI/SPI and various TS multiplexing function
Support PSI/SI correction, directly edit SDT, NIT etc
Support PID filtering and remapping settings
Filling MPEG TS automatically and delete null packet intellectively
Support PCR correction
IF output and loop through supported
RF output scope 48-862MHz, in 0.01MHz step
Output level can be adjusted in 100-113dBuv
Front panel -20dB RF testing output provided
Power off parameter record, it can store 99 channels parameters
SNMP remote control, network upgrade supported

1.3 Specification
MPEG TS Input:
1 ASI input
Comply to EN 50083-9 ASI connector standard
Max bit rate: 170Mbps
Effective bit rate: 1-54Mbps
ASI mode: Byte or burst
MPEG frame: 188/204 bytes packet
Return loss: >10dB
Connector: BNC, 75ohm

QPSK Input (optional QAM/COFDM):
Frequency range: 950~2150MHz
Input level: -25~-65dBm
Symbol rate: 2-45MS/s
Rolling off factor: 0.35
Convolutional code rate: 1/2, 2/3, 3/4, 5/6, 7/8
Interleave depth: I=12
Polarziation: 0/13V/18V(optional)
Connector: F, 75ohm

DS3 Input(optional):
Max input bit rate 44.736Mbps
Format comply with G. 804/G. 752
Connector BNC, 75ohm

DS3 Loop Through Output(optional):
Max output bit rate 44.736Mbps
Format comply with G. 804/G. 752
Connector BNC, 75ohm

MPEG TS Output:
2 ASI outputs
Comply with EN5083-9 ASI connector standard
Max bit rate: 170Mbps
Effective bit rate: 2-51.6Mbps
ASI mode: Byte or burst
MPEG frame: 188/204 bytes packet
Connector: BNC, 75ohm

RF Output:
Output frequency: 47~862MHz
Output level: 100~113dBμV(adjustable)
Output return loss: >10dB
I/Q amplitude unbalanced: <0.1%
I/Q amplitude offset<0.1°
Phase jitter<0.5° RMS
Outband restrain: >55dB
MER: >33dB
C/N: >45dB
Connector: F, 75ohm

QAM Parameter:
Modulation: 16 QAM, 32 QAM, 64 QAM, 128 QAM, 256 QAM, 64B QAM, 256B QAM
Symbol rate: 2~7MS/s, continuous adjustable
Channel bandwidth: ≤ 8MHz

Control and Management:
Front panel
SNMP

Mechanical Parameter:
Voltage: AC 90-260V 50/60Hz
Consumption: 45W
Operating temperature: 0~50Centigrade
Humidity: 10%-90%
Dimension: 400mm(L)X430mm(W)X45mm(H)
Weight: 6kg
