DWDM, Oadm Module, DWDM Device (100G, 200G DWDM)

Name: DWDM, Oadm Module, DWDM Device (100G, 200G DWDM)
Brand: China-Manufacturer-Directory.com
SKU: 696133845
Availability: InStock
Rating: 4.6 (51 reviews)

Supplier:	Flyin Optronics Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	100G, 200G DWDM
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certificate:	ISO9001: 2008
Package:	ABS Box
Type:	Passive Components
Usage:	Telecommunication

Product Description

100g, 200g DWDM, OADM Module, Cheap DWDM, DWDM device
Features
1. ITU channel spacing
2. Low insertion loss
3. Wide pass band
4. High channel isolation
5. High stability and reliability
6. Epoxy free on optical path

Applications
1. Channel Add/Drop
2. DWDM Network
3. Wavelength Routing
4. Fiber Optical Amplifier
5. CATV fiberoptic System

Parameter		4 Channel		8 Channel
		Add	Drop	Add	Drop
Channel Wavelength (nm)		ITUGrid
Center Wavelength Accuracy (nm)		+/-0.05(100G)/+/-0.1(200G)
Channel Spacing (GHz)		100
Channel Passband (@-0.5dB bandwidth) (nm)		> 0.22(100G) / > 0.5(200G)
Insertion Loss (dB)	In---Drop@drop	2.0		3.2
	Add---Out@add	2.0		3.2
	In---out@other	2.5		5.0
Add/Drop Channel Ripple (dB)		< 0.3
Isolation @Add/Drop Channel (dB)	Adjacent	N/A	> 30	N/A	> 30
	Non-adjacent	N/A	> 40	N/A	> 40
Insertion Loss Temperature Sensitivity (dB/)		< 0.005
Wavelength Temperature Shifting (nm/)		< 0.002
Polarization Dependent Loss (dB)		< 0.1
Polarization Mode Dispersion (ps)		< 0.1
Directivity(dB)(Inputtoadd, Outputtodrop, addtodrop)		> 50
Return Loss (dB)		> 45
Maximum Power Handling (mW)		500
Operating Temperature ()		-10~+75
Storage Temperature ()		-40~+85
Package Dimension (mm)		L100xW80xH10

Ordering information

OADM
	Channel Spacing	Numbe rof Channels	Configuration	1s tChannel	Fibe rType	Fibe rLength	Connector
	1=100G Grid 2=200G Grid	4=4CH 8=8CH	44=4x4Add andDrop 88=8x8Add andDrop	21=CH21 … … 34=CH34 … … 50=CH50 … …	1=BareFiber 2=900um loosetube 3=2mmCable 4=3mmCable	1=1m 2=2m	0=None 1=FC/APC 2=FC/PC 3=SC/APC 4=SC/PC 5=ST 6=LC
