Product Specifications
| Prod Model: |
TBC-3301E-FC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Band Width: |
10 /100m |
| Mode: |
Sm |
| Fiber: |
Single Fiber |
| Distance: |
20km |
| Optical Interface: |
FC |
| Wave Length: |
1310/1550 |
| Colour: |
Silver |
| Power: |
Card Insert |
| Dimensions(Mm): |
115 * 77 * 26mm (L*W*H)(Card Without Metal Box) |
| Humidity: |
5%~90% (No Condensation) |
Product Description
TECHINCAL SPECIFICATIONS
Standard Protocol
IEEE802.3
IEEE802.3u
10/100Base-TX
100Base-FX
Transmission speed
10M/100M auto-negotiation
Transmission mode
Full-duplex and semi duplex(auto-negotiation)
Conversion mode
Media conversion, storage transmission, direct transmission
Interface
UTP: RJ-45
Fiber connector: SC/ST/FC
Twisted-pair
Cat5 UTP cable (the max distance up to 100m)
Fiber Cable
8.3/125, 8.7/125, 9/125, 10/125μ M(the max distance up to 20 -120km)
50/125, 62.5/125μ M(the max distance up to 2km or 5km)
Wavelength
Multi Mode: 850nm
Single Mode: 1310/1550nm
Conversion mode
Media conversion, storage transmission, direct transmission
MAC address
1K
Buffer space
288KB
Packet length
Storage transmission: 2046Bytes, straight-through, infinite.
Time-delay
9.6us
Bit error rate
<1/1000000000
MTBF
80, 000 hours
Power supply
AC100~250V on media converter rack mounts
Power dissipation
<2.5W
Operating temperature
0~50 Celsius degree
Storage temperature
-20~70 Celsius degree
Humidity
5%~90% (no condensation)
Dimensions(mm)
115 * 77 * 26mm (L*W*H)(card without metal box)
