Hangzhou Eric Communication Co., Ltd. >> FC Adjustable Attenuator

FC Adjustable Attenuator

Name: FC Adjustable Attenuator
Brand: China-Manufacturer-Directory.com
SKU: 703448045
Availability: InStock
Rating: 4.9 (148 reviews)

Supplier:	Hangzhou Eric Communication Co., Ltd.
Price:	Negotiable/Piece
Min Order:	5/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	FC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Transmission Medium:	Single-Mode
Structure:	FC
Ferrule Endface:	FC
Number Of Cores:	Single-Core

Product Description

FC Adjustable Attenuator

Features
1. High accuracy mechanical size and excellent compatiblity;
2. Ceramic ferrules
3. Connector avilable: FC, LC, SC, ST etc

Technical parameter:
Attenuation: 1dB, 5dB, 8dB, 10dB, 20dB
Attenuation accuracy: ≤ 5dB -± 0.3dB;
≤ 10dB-± 0.5dB;
>10dB-± 1dB.
Return Loss: PC ≤ -45 dB;
UPC≤ -50 dB;
APC≤ -60dB
Polarization dependent loss: ≤ 0.1dB
Operating temperature: -40oC -75oC.

Parameter Value	Value	Unit
Operating Wavelength	1310/1550 ± 10	nm
Tolerance for 1~5 dB Attenuation	± 0.5	dB
Tolerance for 6~30 dB Attenuation	± 10	%
Return Loss	> 50	dB
Operating Temperature	-40 to +75	C
Polarization Dependent Loss	≤ 0.1	dB
Mating Durability	≥ 1000	cycle

Eric Communication Co., Ltd. is a manufacturer of FTTH optical receivers, SAT-IF optical receivers and CATV optical receivers, EDFA, Optical amplifiers, optical transmitters, with well-equipped testing equipment and strong technical force.

With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in FTTH, HFC and Optical Communication and other industries.

Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs.

We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!
