Fixed Installation LED Display for Indoor Use

Name: Fixed Installation LED Display for Indoor Use
Brand: China-Manufacturer-Directory.com
SKU: 736662415
Availability: InStock
Rating: 4.3 (141 reviews)

Supplier:	Shenzhen HTS Optoelectronic Technology Co., Ltd.
Price:	US $ 920-980/Square Meter
Min Order:	1/Square Meter
Quantity::
Trade Terms:	FOB,CIF,CIP

Product Specifications

Prod Model:	P8
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Display Type:	LED Video Display
Tube Chip Color:	Full Color
Display Function:	Video Display
Scanning Mode:	1/8 Scan
Application:	Meetings
IP Rating:	IP43
Certification:	FCC, CB
System Operating Platform:	WIN XP
Pixel Configuration:	SMD3528
Pixel Pitch:	8mm
Pixel Density:	15625dots/M2

Product Description

Features: 1. Low noise, good cooling, low power consumption, reliable 2. Keep its beatiful pictures and brightness after using for a long time 3. Energy-saving design, rich colors, smooth pictures and good conformity 4. Wide view angle, it keeps its real and wonderful colors from different angles 5. High refresh rate, high gray scale, no flickering, can be used for live TV show Photos LED System Diagram

Item	Parameter
Model	P8
Pixel pitch	8mm
Pixel configuration	1R1G1B
LED type	SMD3528
Module size	256*128mm
Module resolution	32*16
Cabinet resolution	128*128
Cabinet size	1024*1024mm
Density	15625dots/m2
Brightness	1400NIT
Scan method	1/8
Best view distance	≥7m
Max. power consumption	600W/m2
Ave. power consumption	300W/m2
Weight	45kg/m2
Cabinet weight	47kg
Refresh rate	960Hz
Grey scale	8192 levels
Colors	0.54 trillion
View angle	Horizontal: 120°, Vertical: 120°
Color temperature	6500K
Frame frequency	≥60Hz
Out of control pixel rate	<1/10000
MTBF	>5000 hours
Lifespan	50000 hours
Control mode	Synchronous display with control PC by DVI
Working voltage	AC 100/200v 50-60Hz
Control distance	Ethernet cable: 100m, Multi-mode optical fiber: 500m, Singel-mode optical fiber: 20km
Operation temperature	-20 to +60
Operation Humdity	10% to 80%
Protection level	Indoor

Shenzhen HTS Optoelectronic Technology Co., Ltd is a Shenzhen-located high-Tech enterprise which specializes in the R&D, manufacturing, salesand serviceof LED display and LED lighting products. Thanksto the human-base management policy, advanced production machines and test equipments as well as rich options of raw material resource, HTS has developed a professionalplatform to become a modern enterprise. According to the demand of the market HTS has developed a Full product range through industry-chained opetatio model and HTS aims to rank. In the front line of the LEDdisplay industry. Of professional designers and software and hardware systems personnel, creative and unique copy talent.

HTS is located in Dalang, Longhua, Baoan District, which enjoys a group of influential experts in LED industry, a professional R&D team and highly-skilled manufacturing staff. It occupies more than 6000 square-meter free-dust and static-proof production area which covers several automated assembling lines, many advanced production machines and optimized testing equipments. Aim to the high level market, HTS insists developing MID and high-end products, serves the customers as the center of our work, strives for survival on the basis of quality, employs the managing idea of searching development by integrity, we manage to win the customers and the market by our sincerest heart, most advanced technology, best-quality products and most satisfactory service.
