HHY7G&HHY7P Introduction
HHY Series Liquid Level Relay can be used as the liquid level control component in the circuit of 50Hz alternating current, 380V or below 380V rated voltage.
Floatless Level Switch Relay /Liquid Level Relay
Connecting or breaking pump controlled circuit according to the requirements, water can be supplied or drained automatically.
HHY Series Liquid Level Relays are widely used in the automatic control between water towers and wells.
Technical Specification
Product name | Floatless Level Switch Relay/Liquid Level Relay (HHY7G, HHY7P) |
| Model numeber | HHY7G, HHY7P |
| Working power | AC24V, 220V, 380V |
| Working mode | HHY7G(JYB-714): Water supply type |
| HHY7P(JYB-714): Water drain type |
| Water control distance | less than or equal to 100meters |
| Contact form | one group normally open normally close contact |
| Contact capacity | 3A AC220V(resistance) |
| Electrical life | 1*105 |
| Overall dimension | 55*41*92mm |
| Installation | 35mm guide rail and matching outlet style |
Xinling Electrical Co., Ltd. China was established in 1990. The company has 9 sub-branches, more than 100 cooperation units, and 100 direct distributors, 1000.00m2 factory area and 1000 stuffs.
The company mainly produces mini relay, time relay, solid state relay, electric power relay, temperature controller, kilowatt-hour meter, circuit breaker, contactor and some other electrical component which are the first choice of electric net reconstruction. With perfect management system and technical advancement, itsstreng thens the management or enterprise and promotes product quality. The company takes prospering national industry as its own responsibilities, works hard developing economy of China to promote enterprise level.
The enterprise has gained ISO9001 and RVA Quality System Attestation(Netherlands), and its products have gained CE attestation (European Community), and UL Attestation and CCC Safety Attestation in China successively, and have been insured by PICC, besides, their quality has been ensured by quality "three guarantee". As a result, its products are sold well in more than 30 provinces and cities of China and are exported to Europe, America, Middle East, South-Eastern Asia, Africa and so on 20 countries and districts. Successively, the enterprise has been given the titles of Star Enterprise of China, Financial AAA Grade Enterprise, Gold Client of Agriculture Bank of China, and Credit Enterprise of Product Quality.
Xinling --- will create a magnificent tomorrow together with you!
