Product Specifications
| Prod Model: |
FM-1313 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Working Area: |
1300*1300mm |
| Spindle Speed: |
6000-24000rmp |
| Spindle: |
3.0kw Water Cooling Spindle |
| Working Sooftware: |
Windows2000/98/XP |
| Resolution: |
0.025mm |
| Controlling Mode: |
CNC |
| Feed Mode: |
Manual |
| Spindle Number: |
Single-Spindle |
| Spindle Layout: |
Spindle Over |
| Certification: |
ISO |
Product Description
FM-1313 Easy Handle Carving Engraving Cnc Router
Features
1. Fuselage strong deformation, good rigidity, high precision, reliable performance,
Durable in use.
2. The z axis adopts imported high precision ball screw, the smooth movement, ensure
High precision machine tools.
3. X, Y axis adopt rack driving, running speed is three times more than screw machine.
4. Main configuration or chooses import, joint venture brand components, stable performance.
5. Table overall thickening, USES the whole cast iron large gantry.
6. Using domestic well-known brand water-cooled spindle, low noise, large cutting force,
Can ensure bulk processing for a long time.
7. The whole machine structure design, good to ensure long service life.
8. The application of high performance subdivision driver ensure machine high speed and
Precision.
9. Compatible with Type3 / Artcam/Castmate/Proe/CAXA/soft wen tai, etc.
10. Have breakpoints, power failure continued carving function.
Application Industry
Advertising signs, PVC board, chevron board, double color boards, logo production, acrylic
Cutting, plastic molding, characters, crystal cutting, plate making, cutting PVC board, acrylic, blister light boxes, LED/neon groove mould.
| Model | FM-1313 | Customization |
| X.Y.Z axis travel | 1300*1300*150mm | yes |
| Platform dimensions | 1300Χ1300mm |
|
| Max. operating speed | 15m/min |
|
| Max. carving speed | 0-5m/min |
|
| Resolution | 0.025mm |
|
| Resetting accuracy | 0.025mm |
|
| Carving command | G mode*,u00*.mmg*.plt |
|
| Guide rail | Precision work round | Taiwan HIWIN Linear Rail |
| Spindle | 3kw water-cooling spindle | yes |
| Operating voltage | AC380V/50Hz | yes |
| Spindle speed | 6000-24000rpm |
|
| Driving mode | high precision pinion and rack |
|
| Operating mode | Stepper |
|
| Working Software | Windows98/2000/XP |
|
| Compatible Software | Type3 software, Wentai software, Artcam software |
|
| Optional Accesseies |
|
|
| Vacuum absorbing table &Vacuum pump |
|
| Control handle (USB connected controller) |
|
| Dust collector |
|
Jinan Firm CNC Equipment Co., Ltd is located in Jinan city, Shandong province. We are one of the most professional and good reputation manufacturers of CNC router (router CNC, CNC wood router), laser engraving machine, CNC plasma cutter, laser cutting machine, laser marking machine in China
Our main products are CNC router and laser machine, 5 axis machineing center, 4 axis machining center, 3 axis ATCcnc router, General 3 axis CNC router, CNC laser engraving and cutting machine, CNC plasma cutting machine. The application covers woodworking, advertising, Marble, Metal, Non-metal, MDF, plastic, etc. Our machines are widely sold in many countryes, European, American, Africa, Canada, England, and so on.
The aim of Jinan Firm CNC Equipment is to continuously upgrade the technique, to help our customers produce the best quality and high precision products, and offer the best after sale service.
Please feel free to contact us if you need the good quality machine, best price and the reassuring after sale service.
