DLLY-4CDT
Four Floors Transparent Elevator Training Set
1.Overview
Teaching four-story elevator is the most common lift elevator structure made of aluminum sheet, and its structure and the actual lift is exactly the same, and have almost all of the features of the actual elevator. In fact it can be seen as miniaturization elevator. Each action in the elevator is running at a glance, can also be repeated hands-on operation. Enable students to be more intuitive, thorough understanding and grasp of the elevator structure and its operation principle, to achieve a multiplier effect. Therefore particularly suitable for teaching.
Teaching the elevator electrical control system is PLC and AC variable speed (VVVF) control the composition and functions of the hardware structure and the actual elevator exactly the same, with automatic leveling, automatic door switch forward response sedan inside and outside the call ladder signal straight drive, lift the safe operation of the protection functions, as well as the elevator stops, emergency stop, repair, slow, slow down, lighting and fans and other special features.
2.Technical parameter
1, Dimension:900*850*2680
2, Input power:three-phase five-wire) AC380V±10% 50Hz
3.Rated power: ≤ 1KW
4.Enviroment temperature: -10 °C ~ 40 °C
5,Relative Humidity: ≤ 85%
6.PLC:FX2N-64KW
7. Converter component:A7AP,A7NC
8.Control mode: switch / digital dual control and VVVF technology
9, Floor: six
10.Tractor power:90W/380V
11, Weight:<200kg
3. Factory:
Our factory located in Pioneering park overseas Chinese Scholars Jinan city, Shandong Province .
We have very strong technical teams with more than 40 engineers and experienced workers. Our products have exported for more than 7 years.
4. Product range:
1) Electrical technology Know-how Training Set
2) Innovative E-skills &Technology Training Series
3) MCU Technology Training Series
4) Machine Tools Electrical Control Training Series
5) Machine Tools Electrical Control Training Series(Model-type)
6) CNC Machine Tools Maintainance Training Series(Model-type)
7) Building Automatic Training Series
8) PC Training Series
9) Innovative industrial Automatic Control Technology Training Series
10) Pneumatic Training Series
11) Hydraulic Training Series
12) Sensor Training Series
13) Motor Training Series
14) Mechatronic Training Series
15) MPS Training Series
16) FMS Training Series
17) Mechanical Training Series
18) Engrave Machine Series
5. Packaging And Delivery Details:
Packaging Detail:
1). Packaging for training kit: plastic package + carton + plywood pallets
2). Packaging for training equipment: plastic package + plywood pallet
Delivery Detail: 40 to 50 days after Received advanced payment.
6.After-Service And Training for Foreign User
1) For our exported equipments, the Warranty is one year, within one year, if there is any problem for spare parts(except damage by man-made) We can supply and replace free of charge. And if after one year, we also supply the service. The difference is user need to pay it.
2) We dispatch our professional and experienced engineer to install equipments and make training for th
