Product Specifications
| Prod Model: |
FPLM |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Height: |
30-70mm |
| Outer Diameter: |
200-360mm |
| Type: |
Automatic Wrapping Machine |
| Automatic Grade: |
Automatic |
| Driven Type: |
Electric |
| Packaging Type: |
Cartons |
| Applicable Industry: |
Medical |
| Application: |
Cleaning, Detergent |
Product Description
Feature:
1. PVC, PE glue film and PP COM knitting or knitting paper can be used to carry out winding package with the way of high-speed.
2. Touch screen interface (man-machine interface) can further facilitate the operation of machine.
3. Engulfing pattern arm type is adopted, direct current motor drive is utilized and rotation engulfing shall be smooth. The electric way is adopted to adjust the size of engulfing arm without artificial adjustment. When the specification of the product is changed, it will be faster and more convenient.
4. The annulation micro-computer automatic packaging machine produced by the company is the computer package machine with PLC automatic control system. The working stability is high and it is able to memorize 99 different kinds of package specifications.
Jiangsu Handing Machinery Co., Ltd. is a private enterprise which was established in May 2002 (abbreviationHD), meanwhile, it was founded with the spreading of reform and opening up of China. It was an unknown enterprise locating in Nanxiashu Town Changzhou City Jiangsu Province in the earlier time and owned dozens of employees, however, it has become famous with the deepening insight of the enterprise and by absorbing excellent talents in different fields. Meanwhile, it is an enterprise that develops to be competent for independent research and innovation, offers new type of machines featuring with high productivity and efficiency and durability for the international wire, cable, special cable and data cable manufacturing industry and gradually keep touch with the globally well-known enterprises in the industry of manufacturing wire, cable, special cable and data cable.
| Model | HD70mm | HD100mm | HD120mm | HD140mm | HD180mm | HD210mm |
Height
| 30-70mm | 50-100mm | 70-120mm | 70-140mm | 90-180mm | 100-210mm |
| Outer diameter | 200-360mm | 220-460mm | 220-460mm | 300-600mm | 320-600mm | 400-800mm |
Single side
| 30-120mm | 40-160mm | 40-160mm | 60-200mm | 80-200 | 80-200 |
Inner diameter
| 140mm | 150mm | 160mm | 180mm | 200mm | 250mm |
Weight of packing
materials | 25kg Max | 35kg Max | 40kg Max | 100kg Max | 150kg Max | 200kg Max |
| Package material | PVC PE PP Pliofilm | PVC PE PP Pliofilm PP Woven belt |
| Material thicknessl | 0.03-0.07mm | 0.03-0.07mm | 0.03-0.07mm | 0.03-0.07
0.9-1.2mm | 0.03-0.07
0.9-1.2mm | 0.03-0.07
0.9-1.2mm |
| Material width | 40-60 mm | 40-60mm | 40-60mm | 80-100mm | 80-120mm | 80-120 mm |
