Front End Loader (Cummins engine)

Name: Front End Loader (Cummins engine)
Brand: china-manufacturer-directory.com
SKU: 681241102
Availability: InStock
Rating: 4.5 (92 reviews)

Supplier:	Qingzhou Hongyuan Vehicles Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Set
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	ZL20F
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Loading:	1600kg
Bucket Capacity:	1.1m3
Dumping Height:	2.8m or 3.1m
Diesel Engine:	Cummins 4bt3.9
Engine Power:	74kw(100HP)
Tire Size:	16/70-20 or 20.5/70-16
Wheel Drive:	4WD
Transmission:	Automatic
Operating Weight:	5900kg
Quantity In 20'gp/40'hq:	1set/ 2sets
Walking Mode:	Wheeled
Condition:	New
Type:	Medium-sized Loader
Certification:	CE
Load And Unload Method:	Front Discharge

Product Description

Wheeled Loader, wheel Loader, loader, Loaders, mini loader, multi-function loader, 20 loader
1)CE approved, ISO 9001, CE certification
2)Cummins brand diesel engine, support stronger power
3)Quickly hitch, and various optional tools for meeting different working condition demands
4)Automatic transmission, easy operation.

You are welcome to us have a visit!

Wheel Loader ZL20F Detailed Specifications
Rated capacity	1.0-1.2m 3
Rated weight	2000Kg
Operating weight	5900Kg
performance of bucket being set level	yes
Max. breakout force	40KN
Max. grade ability	30
Total of three time: lifting, dumping, lowering	9.8S
Max. dump height	3100mm
Max. ground clearance	885
Min. ground clearance	340
Wheel base	2160
Tread	1470
Overall dimensions(L× W× H)	5630 × 2100× 2850mm
Engine
Model	Cummins 4BT3.9
Pattern	Inline, water cooled, dir, inject, four strokes
Number o cylinders-internal diameter* strokes	4-100× 115
Max. torsion	206Nm
Rated power	74kw(100HP)
Min. fuel consuming rate	221g/kw. h(243g/kw. h)
Specified rotational speed	2200r/min
Transmission	Gear box separated from torque converter
Model of torque device	YJ280
Pattern	3-element, single stage
Pattern of gearboxes	full-power shift, countershaft type
Number of gear shift	2 forward, 2 reverse
Max. travel speed	24km/h
Main reducer type	arc taper gear, moderation of first grade
Pattern of wheel side moderation	planed gear moderation of single
Tyresize	16/70-20
Front tyre pressure	220Kpa
Rear tyre pressure	180Kpa
Steering system
Pattern	B225-250
Steering angle(each direction)	± 35
Min. turning radius(outside of bucket)	4239mm
Working hydraulic system
Valve distributing working	ZL20E-04T. QW
Working pumps	CBG2063
Brake system	air assisted oil type four wheel brake
Parking brake	Soft axle control, outside bunch drum type
Fuel capacity	80L
Pressure of working hydraulic system	160Kgf/cm 2

Established in 2005, Qingzhou Hongyuan Vehicle Co., Ltd. is a leading manufacturer and exporter of ZL serial wheel loader in China, which is concerned with the design, development and production of Wheel Loader. All of our products approved CE certification, that's accordingly with international quality standards and are greatly appreciated in a variety of different markets throughout the world.

Our company is specialized in producing mini construction machinery, products cover ZL series wheel loader, mini wheel loader, Multi-Function wheel loader and with different varieties tools which would make one machine for meeting different working condition requirements. Model: ZL08, Z10, ZL12, ZL15, ZL16, ZL18, ZL20, ZL28, ZL30, ZL50, SHM610, HY910, HY712. Tools: Hydraulic quickly coupling, pallet fork, hydraulic pallet fork, hydraulic snow blade, snow bucket, snow blower, 4in1 bucket, screen bucket, hydraulic grapple fork, sweeper, driller, mixer, clamp bales, etc.

Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction. Products successfully established long term business relationship with Australia, whole Europe, South America and Middle East.

Now we are looking for dealers and distributors to promote our products in worldwide markets. Sincerely welcome world friends to contact for business discussion and cooperation based on mutual benefit. We are looking forward to receiving your inquiries. If you are interested, please visit for more information about us.
