Vertical Straight Line Beveling Machine
Glass Machine Specifications
1. Different wheels with pneumatic polishing for option
2. Manual control type
3. Stable running and simple operation
Module: YD-BM-Series
a. Wheel number: For option
b. Glass thickness: 5-19mm
c. Bevel angle: 3-30 degree
d. Max. bevel width: 35 mm
e. Glass speed: 0.8-3 m/min
f. Pressure: 6kg/cm2
g. Min. Glass size: 150x150mm
h. Compress air consumption: 1It/min
Warranty: one year
| Model Number | YD-BM-9 | YD-BM-10 | YD-BM-10 S | YD-BM-10-45 | YD-BM-11 | YD-BM-13 |
| Total nr.of spindle | 9 | 10 | 10 | 10 | 11 | 13 |
| Glass thickness(mm) | 5-19 | 5-19 | 5-19 | 5-19 | 5-19 | 5-19 |
| Min.glass size(mm) | 150×150 | 150×150 | 30×30 | 150×150 | 150×150 | 150×150 |
| Bevel angle (degree) | 3-30 | 3-30 | 3-45 | 3-30 | 3-30 | 3-30 |
| Max.bevel width(mm) | 35 | 35 | 35 | 35 | 35 | 35 |
| Glass speed(m/min) | 0.8-3 | 0.8-3 | 0.8-3 | 0.8-3 | 0.8-3 | 0.8-3 |
| Compressed air Consumption(It/min) | <1 | <1 | <1 | <1 | <1 | <1 |
| Power(kw) | 21 | 23.5 | 25 | 23.5 | 25 | 30 |
| Outer dimension(m) | 7.0×1.2×2.6 | 7.2×1.2×2.6 | 7.2×1.2×2.6 | 7.2×1.2×2.6 | 7.2×1.2×2.6 | 8.0×1.2×2.6 |
| Weight(kg) | 3000 | 3500 | 3500 | 3500 | 4000 | 4500
|
Guarantee and After-sale Service:- One year guarantee for whole machine.
- 24 hours technical support by e-mail.
- Use-friendly English software, user manual and detailed Videos/CD.
- We will provide all spare parts needed for maintenance of the equipment.
- Professional after-sales service team support face-to-face training and installation to customer's factory.
Why choose Ladglass?1. Widely used in different industry2. High precision and reputation3. CE Certificate High quality parts4. Competitive price5. Fast delivery6. Best service Welcome your inquiry and we will try our best to help you choose a right machine!
LIAODA(LAD) Glass Machinery Co., Ltd. is the consignee of Yuanda Glass, which is one of the leading glass machinery designer and fabricator in China in manufacturing popular glass cold and hot processing machinery.
Since 1988 we have worked out first Chinese glass edging machine, with our continuous research and development, in 2000, our first horizontal flat glass tempering furnace has came into being, now hundreds of our intelligent and diligent machines have been running at the sites of domestic and overseas.
All our engineers have years of working experiences in glass fabricating and glass machine manufacturing. On the base of absorbing the latest technologies, we know very well the advantages and disadvantages of all types of existing glass machines, therefore our compact design and sophisticated manufacturing center enable us to construct the most top quality of glass machines at the possible lowest cost.
A LITTLE MORE PRACTICAL, A LITTLE MORE INNOVATIVE is our Motto, on the way of modernization and globalization, we will commit ourselves to satisfy your requirements and our full experiences will absolutely be beneficial to any kind of your needs in flat glass processing.
