Product Specifications
| Prod Model: |
TS-P9 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Network Type: |
GSM |
| Band: |
Universal Quad-Band |
| GPS Moudle: |
Mtk |
| GSM Antenna: |
Internal |
| GPS Antenna: |
Internal |
| Battery: |
Built-in, 1450mAh |
| Customization In Color: |
Yes |
| Software Customization: |
Yes |
| Type: |
GPS Tracker |
| Use: |
Automotive&Hand Held |
| Screen Size: |
No Screen |
Product Description
1.1 Working Voltage: 3.8V DC
1.2 Battery Capacity: 1450 mA/H
1.3 GSM Band: 850/900/1800/1900MHz
1.4 GPRS: Class12, TCP/IP
1.5 GSM Antenna 50Ω Linear polarization passive PiFA antenna
1.6 GPS Frequency: 1575MHz 20Channels
1.7 GPS Tracking Sensitivity: -159dBm
1.8 GPS Capturing Sensitivity: -144dBm
1.9 GPS Locating time: Cold start28s(Open sky)
Hot start2s(Open sky)
1.10 GPS precision: 10m(2D RM)
1.11 GPS Antenna: 50Ω Circular polarization 360° Active ceramic antenna
1.12 Working Temperature: -20~+70
1.13 Working Humidity: 20%~80%RH
1.14 Measurement: 80× 50× 12 mm
2: Characteristics
2.1 Online web platform, the historical and current location can be checked.
2.2 E-fence function.
2.3 Hijack alarm, 9 SOS numbers can be preset.
2.4 remote voice monitoring.
2.5 Low battery alarm.
2.6 Inlayed 3D accelerator, moving and static state, energy smart.
2.7 Change the time interval of uploading automatically according to the speed.
2.8 Admin checks the altitude and longitude and location information by texting.
2.9 Four LED signal indicators: Blue GSM LED, green GPS LED, red SOS and charging LED.
2.10 AGPS solutions, shorter locating time, higher precision.
As a member in fast expanding thing system industry, Shenzhen Thingsys Co., Ltd. has been involved in R&D, production, sales and service of GPS trackers and related products for 5 years. We're one of the most experienced company which offers GPS tracking products and GPS tracking system solutions while we also have OEM and ODM service to our end customers or middle customers.
We have been earning good reputation widely across the world depending on our sophisticated experience and advanced technology capability into GPS tracking industry and GPS related product, including software and hardware. We have been also engaged to establish excellent application of GPS tracking products for local state communication companies, industry operator, government, social community, etc.
We've been striving for excellent work in offering our customers software and hardware of GPS tracking, comprehensive solution and customized requirement, with great efforts from our talented engineers of software and hardware in our R&D department.
We have our own production line together with advanced production facilities, test facilities and strict system of quality control, which will assure that any one of our products and solutions are really in warranty for the functionality and duration of our quality.
Harbored with service concept of "Partnership, Double-Win", we're pursuing advanced trustable stable functioning products and solutions with invented products, rational price and perfect technology support. We're looking for a grow-up and strengthen-up together with you in a fast expanding world connected by things.
