Categories
Supplier: | Jinan Sinoheng Import and Export Co., Ltd. |
---|---|
Price: | US $ 30000/Piece |
Min Order: | 1/Piece |
Quantity:: | |
Trade Terms: | FOB,CFR,EXW |
![]() |
Prod Model: | GR100 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Operating Weight(Standard): | 7000kg |
Rated Power/Speed: | 75/2400kw/Rpm |
Type: | Grader |
Certification: | ISO9001: 2000 |
Condition: | New |
Basic specification | |
Engine model | 4BT3.9 |
Rated power/speed | 75/2400kw/rpm |
Dimension(LxWxH) | 6880×2375×3150mm |
Operating weight(Standard) | 7000kg |
Performance specification | |
Travelling speed ,forward | 5\10\20\39km/h |
Travelling speed ,reverse | 8\25km/h |
Tractive force(f=0.75) | 41.6KN |
Max. gradeability | 20% |
Tire inflation pressure | 350KPa |
Working hydraulic pressure | 16MPa |
Transmission pressure | 1.3~1.8MPa |
Operating specification | |
Max. steering angle of front wheels | ±50° |
Max. lean angle of front wheels | 17° |
Max. oscillation angle of front axle | ±15° |
Max. oscillation angle of balance box | |
Frame articulation angle | ±27° |
Min. turning radius using articulation | 5.9m |
Biade | |
Maximum lift above ground | 300mm |
Maximum depth of cutting | 350mm |
Maximum blade position angle | 45° |
Blade cutting angle | 28°_70° |
Circle reversing rotation | 120° |
Moldboard width X height | 3048×500mm |
