Green Solder Mask Hf Circuit PCB

Name: Green Solder Mask Hf Circuit PCB
Brand: china-manufacturer-directory.com
SKU: 729161795
Availability: InStock
Rating: 5 (71 reviews)

Supplier:	Fulltronics Corporation Ltd.
Price:	US $ 6/Piece
Min Order:	5/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	OEM
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Base Material:	Fr4
Copper Thickness:	1oz
Board Thickness:	1.6mm
Min. Hole Size:	0.1mm
Min. Line Width:	0.1mm
Surface Finishing:	Immersion Gold
Production Process:	Semi-Additive Process
Material:	Epoxy Paper Laminate
Structure:	High Frequency PCB

Product Description

OEM/ODM/EMS Services for PCBA:
PCBA, PCB Board assembly: SMT & PTH & BGA
PCBA and enclosure design
Components sourcing and purchasing
Quick prototyping
Plastic injection molding
Metal sheet stamping
Final assembly
Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
Custom clearance for material importing and product exporting
Capability - SMT
Lines 9(5 Yamaha, 4KME)
Capacity 52 million placements per month
Max Board Size 457*356mm. (18"X14")
Min Component size 0201-54 sq. Mm. (0.084 sq. Inch), long connector, CSP, BGA, QFP
Speed 0.15 sec/chip, 0.7 sec/QFP
Capability - PTH
Lines 2
Max board width 400 mm
Type Dual wave
Pbs status Lead-free line support
Max temp 399 degree C
Spray flux add-on
Pre-heat 3

If you need to get a formal quotation, please provide the spec as below:
1. PCB files in gerber file, . Pcb or. Pcbdoc formart
Please feel free to contact Fulltronics team. We are here ready to assist you with our professional skills and cheerful services

Stencil size/range:	736x736mm
Minimum IC pitch:	0.30mm
Maximum PCB size:	1200x 500mm
Minimum PCB thickness:	0.35mm
Minimum chip size:	0201 (0.2x0.1)/0603 (0.6 x 0.3mm)
Maximum BGA size:	74x74mm
BGA ball pitch:	1.00mm (minimum), 3.00mm (maximum)
BGA ball diameter:	0.40mm (minimum), 1.00mm (maximum)
QFP lead pitch:	0.38mm (minimum), 2.54mm (maximum)
Frequency of stencil cleaning:	1 time/5 to 10 pieces

Turn Times:	Quick turn are our Specialty
Volume:	One piece to low valume production quantityes Low cost first article builds Schedule deliveries
Assembly type:	Surface mount(SMT) assembly Thru-hole Mixed(surface mount and thu-hole) technology Single or double sided placement Cable assembly
Components type:	Passive components: As small as 0402 package As small as 0201 with design review Ball Grid Arrays(BGA): As small as .5mm pitch
Stencil:	Laser cut stainless steel
Parts procurements:	Turnkey(we supply the parts) Consigned(you supply the parts) You supply some parts, we do the rest
Solder type:	Leaded Lead-free/ROHS compliant
Other capabilities:	Repair/rework services Mechanical assembly Box build/electromechanical assembly Mould and plastic injection.

Fulltronics Corporation Ltd is a manufacturer and exporter specializing in Printed Circuit Board fabrication, Assembly and development from the start of 2002

In the early years our core business consist of fabrication of prototypes pcbs, High frequency pcbs, multilayer pcbs, flex pcbs and rigid-flex pcbs for companies of home and abroad. All PCBs are manufactured with advanced quality control systems and are recognized by ISO-9001 and TS16949, UL Certification and ROSH. In 2006 Fulltronics set up an assembly house enabling us to offer a fully integrated array of services, including SMT Assembly, T/H Through Hole Assembly, wire Assembly, Box-build&assembly and functional testing to ensure the highest level of quality control. You can choose any of the procedure you need.

Today our products are applied for medical, defence, broadcasting, telecommunication systems, Industrial control, traffic intelligence systems, auto industry, agriculture and so on. We manufactured products keeping high pace with newly technology developments. Fulltronics Corporation combines fashion and application well to satisfy diverse of customers requirments.

For the most, we take pride in providing excellent quality Products at very competitive prices, outstanding service and timely delivery. If you have any PCB or PCB Assembly projects, just give us opportunities, we perfect your ideas.
