Handheld OTDR for Testing (Fh05000)

Name: Handheld OTDR for Testing (Fh05000)
Brand: china-manufacturer-directory.com
SKU: 721663125
Availability: InStock
Rating: 4.6 (143 reviews)

Supplier:	Zhejiang Guangsu Communication Technology Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	FH05000
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Energy Meter
Display:	Digital
Power Meter Connection:	USB

Product Description

FHO5000 series optical time domain reflectometer is light d communication on the various aspects of the user needs to launch a new generation of intelligent optical fiber communication measurement instruments. As urban and rural communication increasingly packtized network, tests on the fiber optic network by the long distance, the centralized gradually evolved into today's short distance and diversification. Therefore FHO5000 is a good way to save the cost of user input, and not to reduce the test performance.

Model	FHO5000
Wavelength measuring	1310/1550nm
Dynamic Range	34/32dB
Event dead zone	0.8m
Attenuation dead zone	4m
Pluse width	3ns~10us
sampling resolution	Mix 0.25m
sampling site	Max 128,000 point
Distance accuracy	±(1m+test distance310-5+ sampling resolution)(without refringence)
Data store	More than 40000 test curve
Red light source	10Mw,CW/2Hz
Interface	Ethernet interface,3 USB interface(Type A2, Type B1)
Display	7inch TFT- LCD(can choose touch screen fuction)
Battery	7.4V\4.4Ah(with Aviation certification),continuously work 6 hours
Operation temperature	-10~+50 degree centigrade
Store temperature	-20~+75 degree centigrade
Size/weight	25316873.5mm/1.5kg(include battery)
Attachment	Host\12Vpower source adapter\lithium battery\FC adapter head\USB line\quick guide\CD\carry bag
Option	SCadapter head \STadapter head\bare fiber adapter\200mfiber jumper (FC/PC_FC/PC)

Zhejiang Guangsu Communication Technology Co., Ltd. is a professional company business optical communication instrument and lines of communication tools. Production, sales, maintenance, acting as a whole. Domestic and foreign companies and a number of optical communication products suppliers to maintain long-term technical support and cooperation, but also Japan Fujikura(FUJIKURA)\Henghe (YOKOGAWA)\ Japanese Ancient River (FURUKAWA)\Japan ( SUMITOMO )\Canada EXFO, such as the company' S optical communication instrument and data communication the test instrument, instrument agents.

The company in line with" Sincerity-oriented, to convince the people" service idea. We provide for our various customers reliable quality and superior performance products.

Guangsu Technology Co., Ltd will be all-around the ground to ensure that your communication quality.
