Supplier: | Shenzhen Lianxin Testing Equipment Co., Ltd. |
---|---|
Price: | US $ 14000-21000/Piece |
Min Order: | 1/Piece |
Quantity:: | |
Trade Terms: | FOB,EXW,others |
![]() |
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
---|---|
Certification: | RoHS |
Control Type: | Digital |
Type: | Temperature Controller |
Display Type: | LED |
Material: | Stainless Steel |
Usage: | Cold and Hot Shock Equipment |
Brand: | Lianxin |
GB2423.1-89 Low temperature test method | |||||
GB2423.2-89 High temperature test method | |||||
GB12423.22-89 Temperature change test | |||||
GJB150.5-86 Temperature impact test | |||||
GJB360.7-87 Temperature impact test | |||||
Technical parameters | |||||
Test method | TS100 | TS150 | TS200 | ||
Model | 100L | 150L | 200L | ||
Inside Volume | (High greenhouse,Low greenhouse,Test chamber) | ||||
Performance | High greenhouse | Preheat temperature range | RT+20ºC-+200ºC | ||
Heating up time | .+20ºC-+200ºC30min | ||||
Low greenhouse | Preheat temperature range | RT-80ºC | |||
Cooling time | .+20ºC-80ºC about 80min | ||||
Try greenhouse impact | Temperature uniformity | ≤2ºC | |||
Temperature Shock range | .-55ºC-+180ºC | ||||
Temperature recovery time | ≤5min | ||||
Conversion time | ≤10s | ||||
SIZE (D*W*H)(mm) | 400*500*500 | 500*600*500 | 500*700*600 | ||
Material | Inner material | SUS304 Mirror stainless steel plate | |||
Outside material | SUS304 Wire drawing of stainless steel plate or A3 spraying plastics | ||||
Thermal insulation | Superfine glass wool or polyurethane foam | ||||
Test chamber structure | High greenhouse | Heater | Nickel-chromium alloy heating wire heater | ||
Draught fan | Centrifugal fan | ||||
Low greenhouse | Heater,cooler | ||||
Draught fan | Centrifugal fan | ||||
Refrigeration system | Pneumatic cylinder | High temperature, environment temperature, low temperature exposure with each tuyere driver | |||
Air compressor | Provide compressed air compressor driven by pneumatic tuyere (options) | ||||
Refrigerating method | Mechanical compression binary cascade refrigeration | ||||
Refrigeration compressor | Semi-closed piston | ||||
Refrigerant | R404A and R23 | ||||
Condenser | Stainless steel welded plate heat exchanger | ||||
Controller | Color LCD touch screen controller imported from Japan or Switzerland PCD programmable controller | ||||
Power supply | AC380±10V 50±0.5HZ Three-phase five wire | ||||
Power | 35KW | 40KW | 45KW | ||
Circulation cooling water | Water pressure:0.2-0.4Mpa Water temperature≤30ºC | ||||
Compressed air | 0.6-0.8Mpa | ||||
Safety device | Leakage protection, water protection, overtemperature protection, quick fuse compressor over-voltage protection and current protection | ||||
Choose the configuration | Remote monitoring computer RS232 communication interface, control software, the recorder |
