1. FOX® -8H (liquid) and 8HP (powder) is a high performance 100% poly-carboxylate based polymer, specifically developed as an effective dispersant, fluidifier and high range water reducing agent for concrete and other mineral materials. 8H (8HP) is a neutral concentrate grade; It is mainly used as a raw material to produce different types of high performance water reducers for targeted industrials.
2. Special Features:
8H (8HP) performs water-reducing effect, categorized as ASTM Type A admixture with superior benefits from the technology and the quality:
-Very effective dispersing power, largely reduces required dosage
-Good stability, producing extended slump life
-Homogeneous plasticizing property with a unique cohesive characteristic, thus preventing segregation and bleeding
-Promotes usage of higher dosage or volume of cementitious supplementary materials such as silica fume, fly ash and blast furnace slag.
-Versatile disperser for various types of cement and minerals including gypsum, ceramic, ion-oxide pigment.
3. Uses
8H (8HP) is mainly used as a major ingredient to produce a high performance water reducers or plasticizers for the following applications
-High performance concrete
-Precasting
-Self-compacting concrete
-Pumpable or flowable concrete
-Concrete containing silica fume, fly ash or Blast furnace slag
-Specially shaped concrete elements
-Architectural concrete
-Lightweight concrete
8H (8HP) can also be used as-is for above-mentioned applications. However, due to variations in chemical composites of cements and other materials used and for different application requirements, it is not suggested to use 8H (8HP) directly in concrete or other materials without evaluation. The optimal performance of 8H (8HP) in applications should be obtained through trial mixes and/or through formulation adjustments by the users. For precast products processed in elevated temperate such as steam curing, use Simon 600. For technical support, please contact FuClear technologies Inc.
4. Special notes
Do not use 8H (8HP) with additives containing naphthalene sulfonate. Unreliable rheologic behaviours may be experienced. Do not use 8H (8HP) for temperature treated concrete or other materials. Use Simon 600.
5. Packaging
Available in 200 kg (180 L/ 48 gal) drum and 1000 kg (893L/ 236gal) tank for 8H (liquid), and 25kg plastic bag for 8HP (powder form)
6. Storage
8H should be stored at temperature 5- 40C (40-104 F). When It freezes, full strength can be restored AFTER COMPLETE THAWING AND THOROUGH AGITATION. Keep container closed when it is not in use. Do not store the product directly under sunlight.
7. Shelf life
The shelf life is twelve (12) months when it is packed with a new drum or tote tank.
8. Handling
8H (8HP) shows negligible toxic, hazardous, and corrosive. Comprehensive instructions are given in the Material Safety Data Sheet available from Fuclear sales offices.
|
Item |
Standard |
|
Fox® - 8H(20%) |
Fox® - 8H(40%) |
Fox® - 8HP |
|
Physical form |
Viscous liquid |
Powder |
|
Density, kg/m 3 |
1.05± 0.02 |
1.12± 0.02 |
510± 10 |
|
PH(23 degree) |
9.0± 0.5 |
9.0± 0.5 |
9.0± 0.5
20% water solution |
|
Solid Content (%) |
20.0± 1.0 |
40.0± 1.0 |
98.0± 1.0 |
|
Cl- Content (%) |
≤ 0.10 |
≤ 0.10 |
≤ 0.10 |
|
Na2SO4 Content (%) |
≤ 4.0 |
≤ 4.0 |
≤ 4.0 |
|
Water reducing rate of mortar(%) |
≥ 20 |
≥ 20 |
≥ 20 |
FuClear is a Canadian Technology-based company. It established its manufacture plant in Suzhou, China. FuClear's building material lines are developed and produced by FuClear Building Material Co., Ltd., a sub-company of Fuclear Technologies Inc., manufacturing and supplying FOX-8H products for the market in China as well as worldwide. FuClear is an ISO 9001 and ISO 14001 certified company.
Application
FOX-8H, poly-carboxylate superplasticizer, has a very high water reducing capacity. It is a most effective type of water reducer, plasticizer and disperser for use to promote high strength, excellent flowability, pumpability and workability, and efficient dispersion for cement, gypsum and ceramic materials and products.
Grade
FOX product line has following grades to meet the needs for difference uses and customers.
FOX-8H Polycarboxylate polymer, used as a major ingredient for Superplasticizer formulations.
FOX-8H HES Polycarboxylate superplasticizer concentrate, formulated
For High early strength.
FOX-8HP In powder form.
