1. High quality
2. Competitive price
3. Fast delivery
4. Excellent service
Original engine;
World famous brand hydraulic system and other key parts;
Excellent quality with competitive price
| Items | Unit | Parameters |
| Operation weight |
| Kg | 5960 |
| Bucket capacity |
| m³ | 0.09-0.23 |
| Engine | model |
| 4TNV94L |
| no.of cylinders |
| 4 |
| output power | kw/rpm | 39.8/2200 |
| max.torque/speed | N.m | 210/1320 |
| displacement | L | 3.054 |
| Main performance | traveling speed | km/h | 4.2/2.2 |
| rotary speed | r/min | 11 |
| gradeability | ° | 35 |
| ground pressure | kPa | 32.5 |
| bucket digging force | kN | 48.3 |
| arm digging force | kN | 32.5 |
| maximum traction | kN | 50.5 |
| the main pump rated flow | L/min | 156.2 |
| main safty vavle pressure | Mpa | 24.5 |
| pressure of travel sysrem | Mpa | 22 |
| pressure of swing sysrem | Mpa | 21 |
| pressure of pilot sysrem | Mpa | 3.5 |
| Oil capacity | fuel tank capacity | L | 110 |
| hydraulic tank capacity | L | 85 |
| engine oil capacity | L | 12 |
| Apperance size | total length | mm | 5860 |
| total width | mm | 1920 |
| total height | mm | 2585 |
| width of platform | mm | 1780 |
| total width of chassis | mm | 1920 |
| length of crawler | mm | 400 |
| wheel base of crawler | mm | 1990 |
| track gauge | mm | 1500 |
| ground clearance of counterweight | mm | 710 |
| min.ground clearance | mm | 385 |
| dozer(width/height) | mm | 1920×340 |
| Working scope | max.digging height | mm | 5630 |
| max.dumping height | mm | 3945 |
| max.digging depth | mm | 3830 |
| max.vertical wall digging depth | mm | 2680 |
| max.digging reach | mm | 6130 |
| min.swing radius | mm | 2460 |
| min.tail swing radius | mm | 1660 |
| max.dozer lifting height | mm | 390 |
| max.dozer cutting depth | mm | 560 |
| Standard configuration | length of boom | mm | 3000 |
| length of arm | mm | 1600 |
| bucket capacity | m³ | 0.23 |
