Product Specifications
| Prod Model: |
PF Series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Cement\Magnesium\Lime\Ore Dressing\Sand Production |
| Certificate: |
ISO9001,ISO14000 |
| Type: |
Impact Crusher |
| Experience: |
More Than 50 Years |
| Factory Area: |
55000m2 |
| Design: |
by Professional Engineer |
| Installation: |
Under Our Engineer's Guide |
| After Sale Service: |
We Offer |
| Testing: |
We Offer |
| Spare Parts: |
We Offer |
Product Description
PF Series Impact Crusher
Introduction:
PF Series Impact Crusher is mainly used in secondary crushing, and can crush material o f crushing compression strength no more than 320 Maps. It is suitable to produce high rank highway, hydroelectric and building material and such industry as stone.
Features and advantages:
1. Even crushing function of multi-cavities which is suitable to crush hard material.
2. Reasonable design of leveling plate making the finished material finer and cubic-shaped without internal cracks
3. Low and big feed opening make the production line easy to arrange and increase the size of feeding material.
4. Hydraulic start-up which is convenient for maintenance and replacement of wear-parts.
5. New anti-abrasive material which prolong service life of impact hammer, impact plate and liner.
Working principle:
After the ore into the crushing chamber, crushed by the high speed rotary hammer impact, throw to the impact plate in high speed. The ore crushed again under the impact plate's counterattack effect, the rebound ore bounced by impact plate crushed by the hammer impact again. Such repeated until the size of the ore is less than the gap between hammer and counterattack plate, discharge the accepted product from the botom.
Company Name: Henan Zhengzhou Mining Machinery Co., Ltd.
Official Website: http://www.inczk.com/ & http://www.zkcomp.com/
24-hour Free Sales Consulting Phone: 861-0371 -5590 2866.
Company Address: Qiaolou caizhai industrial estate, Xingyang city, Henan Province
Please pay attention to the company's other products:
Price of rotary kiln: http://www.zkcomp.com/calcining/558. Html
Rotary Kiln: http://www.inczk.com/Products/459. Html
Preheater: http://www.zkcomp.com/calcining/605. Html
Cement Mill: http://www.inczk.com/Products/460. Html
Rotary Dryer: http://www.zkcomp.com/calcining/564. Html
Raw Mill: http://www.inczk.com/Products/1373. Html
Ball Mill: http://www.zkcomp.com/grinding/582. Html
|
mode |
specification |
Feed opening size |
Max size |
capacity |
Motor power |
|
( mm ) |
( mm ) |
( t/h ) |
( kw ) |
|
PF-0807 |
ø850x700 |
400x730 |
300 |
15-30 |
30-45 |
|
PF-1310 |
ø1300x1050 |
490x1170 |
400 |
80-140 |
110-160 |
|
PF-1520 |
ø1520x2000 |
830x2050 |
700 |
300-550 |
315-440 |
Henan Zhengzhou Mining Machinery Co., Ltd, was established in 1956 and located in Xingyang of Zhengzhou City of Henan Province, specially produces metallurgical machinery. It covers an area of more than 55000m2 and various building area of 28000 m2. It has the annual income of more than RMB180million in 2008 and now the fixed assets of over RMB80 million. In the plant, there are branches and workshops of cast iron, cast steel, forging, heavy machine tool processing, rivet welding and heat treatment etc. Its perfect and complete equipment, advanced detection means, strong technical force establish good foundation for the reliable production.
Main products include: Jaw style, hammer style, impact style and roll style crusher; Ball mill, direct fired drier, rotary kiln, preheater, coker, magnetic separator, flotation machine, classifier, feeder, hoisting machine and conveyor etc. These complete sets of machinery for cement building material, metallurgy, coking and chemical smelting etc are sold well in the world. Our company also has professional installation and construction teams and perfect after-sales service guaranty system.
With the development of the People's Republic of China, Henan Zhengzhou Mining Machinery Co., Ltd undergoes frequent difficulties and has accomplished over 50 years' brilliant history. Initially from the manufacturing of original single machine till today's series of and complete sets of mining metallurgical machinery, it has made great contribution to the development and utilization of mineral resources of our country. For many years, each spot check and annual examination carried by National Mining Machinery Quality Supervision and Inspection Center for our products is acceptable and our company is always appointed as Credible and Reputed Enterprise by Henan Provincial Administration of Industry and Commerce.
Henan Zhengzhou Mining Machinery Co., Ltd will continue providing excellent products and service for our society, with the guideline of "survival by quality, development by good faith, users supreme". Our company would make sincere cooperation with all circles for mutual benefit and common development.
