High Precision Big CNC Machine Tools Ck-6191b

Name: High Precision Big CNC Machine Tools Ck-6191b
Brand: china-manufacturer-directory.com
SKU: 755874745
Availability: InStock
Rating: 4.5 (109 reviews)

Supplier:	Zhejiang Kaida Machine Tool Co., Ltd.
Price:	US $ 30000-50000SET
Min Order:	1SET
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	CK-6191B
Markets:	North America,South America,Eastern Europe,Southeast Asia,Mid East,Eastern Asia,Western Europe
Spindle Bore:	104mm
Speed:	4 Steps (Stepless in Every Step)
Main Motor:	15kw
Max Swing Over Bed:	910mm
Bed Width:	600mm
Tool Post:	4 Way, 6 Way Is Optional
Process Usage:	Metal-Cutting CNC Machine Tools
Movement Method:	Linear Control
Control Method:	Semi-Closed Loop Control
Numerical Control:	CNC/MNC
Performance Classification:	High-End CNC Machine Tools

Product Description

PRODUCT FEATURES:
Longitudinal and cross feeds are effected by ball leadscrews. Driven by servo motors.
The surface of the bedways is supersonic frequency hardened and precisoion ground with a long service life.
The spinde bore size is 104mm. The spindle system si high in the rigidity and accuracy.

ITEMS	CK6191B/ CK6291B	CK61100B/CK62100B	CK61110B/CK62110B
Max. swing over bed	Ø910mm	Ø1000 mm	Ø1100 mm
Max. swing over carriage	Ø530mm	Ø620mm	Ø720mm
Width of bed	600mm
Maximum turned length	1.5/2/3/4mm
Max. turning length	1350/1850/2850/3850mm
Max. weight between center	2000kg
*over gap	Ø1100 mm	Ø1200 mm	Ø1300 mm
*Effective length of gap	400 mm
Spindle nose	D11
Spindle bore	Ø104mm
Cone hole diameter and taper of spindle hole	Metric Ø120 1:20
Steps of spindle speed(Manual)	4 (riable Within Each Step)
Range of spindle speed	10~90, 20~180, 40~320, 80~630r/min
Rapid feed for Axis Z	10m/min
Rapid feed for Axis X	8m/min
Max. travel of Axis X	520mm
Min. input	0.001mm
Tool post stations	4-way
Tool cross section	40×40mm
External diameter	Ø100mm
Taper of bore	M.T.NO.5
Max. Traverse	250mm
Power of main motor	15KW
Power of cooling pump	370W
2m Overall dimensions(L×W×H)	4200×2000×1930mm	4200×2000×1980mm	4200×2000×2030mm
Net weight	6600Kg	6770Kg	6940Kg
Note : For each additional machine length of 1m, there will be additional net weight of 600kg

Zhejiang Kaida Machine Tool Co., Ltd

Zhejiang Kaida Machine Tool Co., Ltd is located in Zhuji City, China.And only 45 minutes away from Hangzhou Airport.

Our company was founded in 1952 and has a history of more than 60 years in manufacturing lathes, also with a total area of 32 hectares and 1000 staff.Through reformation in 1997, we have been changed from a state-owned enterprise to a joint-stock private enterprise.We got ISO9001 certificate in 1997, CE certificate in1999 and ISO14001 certificate in 2005.

We have a wide variety of products, which can meet different customers' needs:Horizontal machining center, vertical machining center, CNC slant bed lathe, CNC flat bed lathe, manual lathe.

We have a full set of equipment including forging, machining, heat-treating, sheet metal processing, assembling and painting.Specialized technicists in every field enable us to assist our customer in use, learning and programming.Efficient service earn us trust and loyalty from customer.

As an established company, professional competence and perfect service make us to exploit and develop a huge international marketing net.Our export experience started from European and America.We have exported to more than 100 countries.Our main markets are Europe, America, South America, India, Southeast Asia, South Africa.

We are fully confident to meet any challenges or opportunities that present to us.
