Zaozhuang Make Machinery Co., Ltd. >> High Precision Gap Bed Horizontal Lathe Machine (C6236D)

High Precision Gap Bed Horizontal Lathe Machine (C6236D)

Name: High Precision Gap Bed Horizontal Lathe Machine (C6236D)
Brand: china-manufacturer-directory.com
SKU: 760317985
Availability: InStock
Rating: 4.4 (58 reviews)

Supplier:	Zaozhuang Make Machinery Co., Ltd.
Price:	US $ 1/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	C6236D
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Spindle Taper:	Mt6
Thru-Hole Of Spindle:	52mm
Spindle Speed:	30_1600 R/Min (12 Steps)
Motor Power:	3/4kw
Type:	Horizontal Lathe
Processing Accessory:	Chuck CNC Lathe
Tool Holder:	Single-tool Holder CNC Lathe
Power Source:	Electric
Controlling Mode:	Artificial
Automatic Grade:	Semiautomatic
Setting Mode:	Floor-type
Precision:	High Precision

Product Description

· Dealing directly with the manufacture- no middle man!
· The most competitive pricing in the market.
· High quality control standards, such as ISO, CE
· Guaranteed delivery time.
· Prompt attention to the customer inquiries.
· Diverse services for your needs, including sourcing other machinery, inspection goods for you by our engineers, product process tracking and good.

Specifications		Gap	Straight	Gap	Straight		Gap	Straight		Gap
		C62 32D	C61 32D	C62 36D	C61 36D		C62 40D	C61 40D		C62 50D
Center height		160mm		180mm			200mm			250mm
Max. Swing over bed		320mm		360mm			400mm			500mm
Max. Swing over carriage		190mm		190mm			210mm			210mm
Max. Swing in gap		520mm	-	540mm	-		560mm	-		590mm
Effective gap length		200mm	-	200mm	-		200mm	-		200mm
Max. work piece length		500mm or 750mm or 1000mm or 1500mm
Spindle taper		MT 6
Thru-hole of spindle		52mm
Spindle speed		30-1600 r/min (12 steps)
Cross travel		240mm
Compound travel		140mm
Tail stock center sleeve travel		90mm
Tail stock center sleeve taper		MT 4
Motor power		3/4KW
Range of metric threads (kinds)		0.45-20mm(30)
Range of inch threads(kinds)		80-1.75 n/ I"
Long. feed per spindle rev.		0.04-2.16mm
Cross feed per spindle rev.		0.02-1.08 mm
Overall dimensions	Work-piece length 500mm	170011301200 mm
	Work-piece length 750mm	200011301540 mm
	Work-piece length 1000mm	225011301540 mm
	Work-piece length 1500mm	280011301540 mm
Net weight	Work-piece length 500mm	1200kg				1300kg			1500 kg
	Work-piece length 750mm	1400kg				1500kg			1700kg
	Work-piece length 1000mm	1500kg				1600kg			1700kg
	Work-piece length 1500mm	1700kg				1800kg			2000kg

The main products include machine tools like Plano Miller/Plano Milling Machine/Gantry Milling Machine/Planer Milling machine, Conventional Milling Machine & Milling/Drilling Machine, Vertical Lathe, Horizontal Lathe, Radial Drilling Machine, Vertical Drilling Machine, Gear Shaper & Hydraulic Shaper, Press, Shearing Machine, Press Brake, Saw Machine, Riveting Machine, Air Hammer, etc; Accessories like Vice, Angle Clamp, Slotting Head, DRO, Dividing Head, Rotary Table, Grinding wheel balancer, Universal Boring Head, Clamp kits, etc. And the other product range is garage equipments like Cylinder(Blocks) Boring Machine/Fine Boring Machine, Cylinder Honing Machine, Brake Drum Boring Machine, Brake Lathe/Brake Drum(Disc) Cutting Machine, etc.

All of them have adopted modernized ISO Quality Management System, sound operational procedures as well as effective service system. All the commodities are carefully produced and we bear in mind that products with consistent good quality are crucial to the ongoing success of your operations.
