Universal Precision Heavy Metal Gap-Bed Center Engine Lathe Machine (CA6266C)

Name: Universal Precision Heavy Metal Gap-Bed Center Engine Lathe Machine (CA6266C)
Brand: china-manufacturer-directory.com
SKU: 760220855
Availability: InStock
Rating: 5 (141 reviews)

Price:	US $ 1/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

· Dealing directly with the manufacture- no middle man!
· The most competitive pricing in the market.
· High quality control standards, such as ISO, CE
· Guaranteed delivery time.
· Prompt attention to the customer inquiries.
· Diverse services for your needs, including sourcing other machinery, inspection goods for you by our engineers, product process tracking and good.

Specifications		CA6140 CA6240 CA6140B CA6240B		CA6150 CA6250 CA6150B CA6250B CA6150C CA6250C		CA6161 CA6261 CA6161B CA6261B CA6161C CA6261C		CA6166 CA6266 CA6166B CA6266B CA6166C CA6266C		CA6180 CA6280 CA6180B CA6280B CA6180C CA6280C
Max .Swing over bed		400mm		500mm		610mm		660mm		800mm
Max .Swing over carriage		210mm		300mm		370mm		400mm		540mm
Max .Swing in gap		--	630mm	--	720mm	--	830mm	--	880mm	--	1020mm
Effective gap length		--	210mm	--	210mm	--	210mm	--	210mm	--	210mm
Max . work piece length		750/1000/1500/2000/2200/3000/4000mm
Width of bed		400mm
Section of turning tool		25×25mm
Spindle	Spindle speed	10-1400rpm/16-1400rpm(24steps)
	Hole through spindle	52mm ,(80mm),[105mm]
	Spindle taper	No.6(MT6)(Φ90 1:20)[Φ113:20]
Feed	No. of feed	(64 kinds)(for each)
	Range of metric threads	(1-192mm) (44 kinds)
	Range of inch threads	(2-24tpi) (21kinds)
	Range of module threads	0.25-48 (module 39 kinds)
	Range of pitch threads	1-96DP (37 kinds)
Tailstock	Max. tailstock spindle travel	150mm
	Tailstock spindle diameter	75mm
	Taper of tailstock spindle center hole	NO.5 (MT5)
Main motor		7.5KW(10HP)
Packing dimensions (L×W×H mm)	Work piece length 750mm	2440×1140 ×1750		2440×1140 ×1750		2440×1140 ×1750		2440×1140 ×1750		2440×1140 ×1750
	Work piece length 1000mm	2650×1140 ×1750		2650×1140 ×1750		2650×1140 ×1750		2650×1140 ×1750		2650×1140 ×1750
	Overall dimensions for 1500mm	3150×1140 ×1750		3150×1140 ×1750		3150×1140 ×1750		3150×1140 ×1750		3150×1140 ×1750
	Overall dimensions for 2000mm	3650×1140 ×1750		3650×1140 ×1750		3650×1140 ×1750		3650×1140 ×1750		3650×1140 ×1750
	Overall dimensions for 2200mm	4030×1140 ×1750		4030×1140 ×1750		4030×1140 ×1750		4030×1140 ×1750		4030×1140 ×1750
	Overall dimensions for 3000mm	4800×1140 ×1750		4800×1140 ×1750		4800×1140 ×1750		4800×1140 ×1750		4800×1140 ×1750
	Overall dimensions for 4000mm	5680×1140 ×1700		4800×1140 ×1750		4800×1140 ×1750		4800×1140 ×1750		4800×1140 ×1750
Weight (kg)	Length	G.W. N.W.		G.W. N.W.		G.W. N.W.		G.W. N.W.		G.W. N.W.
	Overall dimensions for 750mm	2100 1990		2170 2060		2300 2180		2380 2260		2520 2400
	Overall dimensions for 1000mm	2190 2070		2260 2140		2380 2250		2570 2450		2720 2560
	Overall dimensions for 1500mm	2350 2220		2420 2290		2577 2437		2810 2640		2980 2800
	Overall dimensions for 2000mm	2720 2570		2790 2640		2940 2787		3050 2880		3260 3087
	Overall dimensions for 2200mm	2800 2600		2940 2790		3120 2970		3390 3180		3490 3287
	Overall dimensions for 3000mm	3300 3200		3450 3300		3600 3450		3930 3687		4220 3887
	Overall dimensions for 4000mm	3500 3400		3750 3600		3950 3800		4580 4200		4850 4500

Prod Model:	CA6266C
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Width Of Bed:	400mm
Spindle Taper:	No.6(Mt6)
Spindle Speed:	10-1400rpm/16-1400rpm(24steps)
Main Motor:	7.5kw
Type:	Horizontal Lathe
Processing Accessory:	Chuck CNC Lathe
Tool Holder:	Double-tool Holder CNC Lathe
Power Source:	Electric
Controlling Mode:	Artificial
Automatic Grade:	Semiautomatic
Setting Mode:	Floor-type
Precision:	High Precision

The main products include machine tools like Plano Miller/Plano Milling Machine/Gantry Milling Machine/Planer Milling machine, Conventional Milling Machine & Milling/Drilling Machine, Vertical Lathe, Horizontal Lathe, Radial Drilling Machine, Vertical Drilling Machine, Gear Shaper & Hydraulic Shaper, Press, Shearing Machine, Press Brake, Saw Machine, Riveting Machine, Air Hammer, etc; Accessories like Vice, Angle Clamp, Slotting Head, DRO, Dividing Head, Rotary Table, Grinding wheel balancer, Universal Boring Head, Clamp kits, etc. And the other product range is garage equipments like Cylinder(Blocks) Boring Machine/Fine Boring Machine, Cylinder Honing Machine, Brake Drum Boring Machine, Brake Lathe/Brake Drum(Disc) Cutting Machine, etc.

All of them have adopted modernized ISO Quality Management System, sound operational procedures as well as effective service system. All the commodities are carefully produced and we bear in mind that products with consistent good quality are crucial to the ongoing success of your operations.
