Product Specifications
| Prod Model: |
HL-1900-PCI Baytrail |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
130mm*90mm |
| Packing Or: |
20PCS/Carton or 30PCS/Carton |
| Printed Circuit Board: |
Six Layer |
| Memory: |
DDR3 |
| Integrated Graphics: |
Integrated Graphics |
| Main Board Structure: |
Integrated |
| Main Chipset: |
Baytrail |
| Structure: |
3.5inch |
| SATA Interface: |
SATA1 |
| Maximum Memory Capacity: |
6GB |
Product Description
Product Features:
1, integrated Intel Bay Trail J1900 (2.0 GHz) quad-core processor, 2G DDR3 onboard memory, onboard 4G flash
2, using the latest generation of Intel platform baytrail
3, 4 2.0,1 a USB3.0
4, 1 VGA, 1-way HDMI-mini Interface
5, DC12V Powered by
Product Specifications:
Processor
Integrated Intel Bay Trail J1900 (2.0 GHz) quad-core processor
Chipset
Baytrail
RAM
Onboard 2G memory, 1 * DDR3 SODIMM, maximum support 6GB
Serial ports
/
USB
4 * USB2.0, where the front two USB2.0, USB2.0 pin 2
Ethernet port
1*Realtek 8111E Gigabit Ethernet port
Graphics chip
Intel HD Graphics (CPU integrated)
Display Interface
1*VGA
1*HDMI
Expansion Bus
/
/
Storage Configuration
Onboard 4G flash;1*SATA interface
Front I / O
2 USB2.0;; 1 audio; front a network port 1 channel VGA; 1-way HDMI-mini; DC12V
Working temperature
-20ºC~65ºC
Power mode
DC 12V
Size
130mm*90mm
