Product Specifications
| Prod Model: |
D-20EII-EC-1263-01 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| External Size: |
200x 420x 350 (mm); 7.9 x16.5 x13.8(inch) |
| Steel Thickness: |
2mm for body, 5mm for door |
| Security Level: |
A1 |
| Material: |
Steel Plate |
| Function: |
Anti-theft |
| Lock Type: |
Electronic Lock |
| Certification: |
RoHS |
| Door Type: |
Single Door |
| Appearance Of Height: |
<273mm |
| Appearance Of Width: |
371-460mm |
| Appearance Of Depth: |
301-400mm |
| Password Working Principle: |
Electronic |
| Application: |
Commercial |
Product Description
Hotel Safe with electronic lock and Credit Card function (D-20eii-Ec-1263-01)
Model Number: D-20EII-EC-1263-01
Minimum Order Quantity: 100 Piece/Pieces
Supply Ability: 20000 Piece/Pieces per Month
Electronic safes /Credit card safes / D-20EII-EC-1263-01 / 2mm body, 5m door/ 200x 420x 350mm
**Product photo not prepared yet. Current photo is D-23EII-EC which is different in safes size and 1mm door steel plate thickness. We will update photo as soon as possible.
1) Size & Weight:
- External Size (H x W x D): 200x 420x 350 (mm); 7.9 x16.5 x13.8(inch)
- Net Weight: 11.6± 1kg / 25± 2 lbs (approx)
2) Interior and shelving - no shelf, carpeted bottom
3) Material
- Steel thickness: 2mm for body, 5mm for door
4) Lock & handle
- LED display Electronic lock with push button with magnetic card swipe.
- Password input or card swipe to close and open.
- Motorized opening, mechanical override key
- Time and date settig / 105 previous opening record trail on LED.
5) Security feature
- Two chrome plated 20mm dim solid steel boltwork,
- Inner hinge to prevent hinge cutout
6) Color and Finish
- Durable powder coat Beige or Black or Two tone grey combi (shown in the photo)
- Color option: Other color available for order q'ty over than 300 PCS.
7) Accessory
- 4 anchor bolt holes (2 x bottom, 2 x back), 2 anchor down bolts included.
*Packaging: Bubble wrap, Lock protection foam on front + 8 corner protective foam, 6 side carton.
8) Standard option:
- Customer Logo: Please contact us for MOQ and additional cost.
- Optional Audit trail CEU kit for hotel manager ( including program installation CD, English or Chinese only).
- Add rubber feet on the bottom.
- Please contact us if you have other needs.
** Sales restricted area: None
** Electronic room safe model list
| Model Name | Kgs | thickness
body/door, mm | Lock | Outside size
(HxWxD, mm) |
|
|
| D-18EF | 11 | 2/4 | Electronic or Card, LED display, SJ850 | 178 | 381 | 254 |
| D-23EF-BLK | 14 | 2/4 | Electronic or Card, LED display, SJ850 | 229 | 457 | 381 |
| D-23EF | 14 | 2/4 | Electronic or Card, LED display, SJ850 | 229 | 457 | 381 |
| D-56EF | 23 | 2/5 | Electronic or Card, LED display, AP8222 | 560 | 370 | 445 |
| D-20EII-EC-1263-01 | 12 | 2/5 | Electronic or Card, LED display | 200 | 420 | 350 |
| D-20EII-EC-1263-02 | 14 | 2/5 | Electronic or Card, LED display | 200 | 508 | 370 |
| D-23EII-EC-607 | 13 | 2/5 | Electronic or Card, LED display | 230 | 406 | 356 |
| D-23EII-EC-635 | 14 | 2/5 | Electronic or Card, LED display | 230 | 420 | 380 |
| DR-11EII-607 | 7 | 2/4 | Electronic or Card, LED display | 114 | 305 | 356 |
AIPU is a safes manufacturing company located in Ningbo China.
Our company consist of 3 safes factories and one safes technology research institute in Ningbo with overall 1200 employees and 45 sales branches throughout the mainland China.
We are proud of being safes manufacturer with advanced equipments such as CNC punching machines and lazer cutting machines, and we have more than one hundred safes expert engineers.
AIPU received ISO9001 quality control system and we also have products carrying UL, CE, ETL and many other overseas and Chinese certificates.
We have been building safes from 1991 and have become number 1 market share from 2005 in Chinese domestic market.
Our overall sales volume 2009 was around $52, 000, 000 and $18, 000, 000 was exported to overseas.
We are a major supplier of many large and famous safes companies such as Gunnebo, AMSEC, Stack-On, Gardall, MESA, Pheonix, etc.
Our product range covers wide varity of different safes such as gun safes, fire proof safes, depository safes, hotel safes, finger print safes, etc.
With our accumulated experience in safes building and service, we believe that we could satisfy your need and can be your supplier.
