Hy280 Mini Skid Steer Loader with Special 4 in 1 Bucekt

Name: Hy280 Mini Skid Steer Loader with Special 4 in 1 Bucekt
Brand: china-manufacturer-directory.com
SKU: 678252432
Availability: InStock
Rating: 4.3 (86 reviews)

Supplier:	Tai'an Hysoon Machinery Co., Ltd.
Price:	US $ 1-7000/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,EXW,CIF

Product Specifications

Prod Model:	HY280
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Small Size:	Big Function
Type:	Backhoe Loader
Size:	Small-Scale
Certification:	CE
Condition:	New

Product Description

Engine: Imported Briggs & Stratton Engine
Control system: Hydraulic pilot control with joystick
Steering: 360 degrees Steering
Transmission: Hydraulic transmission
Driven: 4 wheels

Power: 23HP, Total Width: 800mm, Operathing Load: 165kg, Bucket Capacity: 0.15 m3

There are numerous Skid Steer Attachments such as bucket, the backhoe, hydraulic breaker, pallet forks, angle broom, sweeper, auger, lawn mower, snow blower, stump grinder, tree spade, trencher, dumping hopper, ripper, tillers, grapple, tilt, roller, snow blade, wheel saw, and so on, thus ensuring there is a tool for every job you can possibly imagine. If you can think of a job for the skid steer loader, chances are there is an attachment specific to that task.

Item	HY280
	With Rubber Track		With Solid tyre		With Normal tyre		With turf tyre		With Chevron engineering tyre
	mm	inch	mm	inch	mm	inch	mm	inch	mm	inch
Max working height(H3)	2065mm	81.3inch	2032 mm	80inch	2072 mm	81.6 inch	2072 mm	81.6inch	2060mm	81.1 inch
Max pin height(H2)	1803mm	71inch	1769 mm	69.4inch	1809 mm	71.2inch	1809 mm	71.2 inch	1798 mm	70.8 inch
Max dumping height(H1)	1386 mm	54.6inch	1353 mm	53.2inch	1393 mm	54.8inch	1393 mm	54.8 inch	1382 mm	54.4 inch
Max Dumping distance(E)	471 mm	18.5 inch	508 mm	20 inch	468 mm	18.4 inch	468 mm	18.4 inch	480 mm	18.9inch
Max Dumping Angle(α 3)	32°	32°	32°	32°	32°	32°	32°	32°	32°	32°
Rollback of bucket on ground(α 2)	33°	33°	33°	33°	33°	33°	33°	33°	33°	33°
Departure angle(α 1)	18°	18°	15°	15°	19°	19°	19°	19°	18°	18°
Total height(H)	1309 mm	51.5inch	1276 mm	50.2 inch	1316 mm	51.8inch	1316 mm	51.8 inch	1304 mm	51.3 inch
Ground clearance(H1)	123 mm	4.8 inch	90 mm	3.5 inch	130 mm	5.1 inch	130 mm	5.1 inch	119 mm	4.7 inch
Wheel base(L1)	690 mm	27.2 inch	686 mm	27 inch	686 mm	27 inch	686 mm	27 inch	686 mm	27 inch
Overall length without bucket(L3)	1778 mm	70 inch	1778 mm	70 inch	1778 mm	70 inch	1778 mm	70 inch	1778 mm	70 inch
Total width(B2)	800 mm	31.5 inch	903 mm	35.6 inch	903 mm	35.6 inch	1053 mm	41.5 inch	1030 mm	40.6 inch
Bucket width(B1)	820 mm	32.3inch	820 mm	32.3inch	820 mm	32.3inch	820 mm	32.3inch	820 mm	32.3inch
Total length with bucket(L)	2210 mm	87inch	2210 mm	87inch	2210 mm	87inch	2210 mm	87inch	2210 mm	87inch
Turn radius forward turning R	1237mm	48.7inch	1237mm	48.7inch	1237mm	48.7inch	1243mm	48.9 inch	1243mm	48.9inch

Item					HY280
Engine		Rated Power(KW)			14.9KW(20HP)
		Rotating speed(rpm)			3600
Noise (Db)					≤ 95
Hydraulic System		Pressure (Mpa)			17
		Working Time (s)			Raise		dump	Lower
					4.27		1.34	3.31
Technical Parameter				Metric system		English system
	Operating Load			165 Kg		363.8 Lb
	Bucket Capacity			0.15 m 3		5.33 ft 3
	Max Lifting Force			375 Kg		827 Lb
	Travel Speed			0-5.5 Km/h		0-3.4 mile/h
	Operating Weight		Chevron engineering tyre	744 Kg		1636.8 Lb
			With Solid tyre	794 Kg		1750.5 Lb
			With normal tyre	740Kg		1631.4 Lb
			With turf tyre	704 Kg		1552 Lb
			With Rubber tyre	855KG		1884 Lb
Tyre Model		Solid tyre			16× 6-8
		Normal tyre			5.00-8
		Turf tyre			KT-302 18*9.5-8 6P/TL
		Chevron engineering tyre			18*6.5-8
Rim		Solid tyre			4.33R-8
		Normal tyre			3.50D
		Turf tyre			18*9.5-8

Located at the foot of the world famous Mount. Tai, Tai'an Hysoon Machinery Co., Ltd is the first-class professional manufacturer engaged in the research, development and manufacture of miniature engineering machinery in China.

The leading products are Multi-task Mini Skid Steer Loader, Articulated Mini Loader and relevant attachments. It can be mainly used in landscaping, manufacturing, general construction, recycling, gardens, road, building, farm and many other industries.

For example, General Purpose Bucket, 4 in 1 Bucket, Grapple Bucket, Backhoe, Rotary Digger, Excavator, Trencher, Rotary Tiller, Augers, Forks, Dozer Blade, Snow Blade, Snow Blower, Lawn Mower and so on.

All of our products are engineered for safe, user-friendly operation and all models incorporate standard features that offer operators an edge in power, speed, durability, ease-of-use and safety.

We are always orienting our development to the research, manufacture and export of the special loader. Meanwhile, we constantly striving to gain performance advantages and expand our product range so as to win a greater market share.

And we have passed CE approval.

Our products are not only popular in domestic markets, but also have been exported to America, Germany, Australians, Spain, Argentina, Russia, etc. Due to the high quality, we received the extensive approval and trust from our clients all over the world.

We will supply the best service to you!
