IEC60068-2-1 Xenon Lamp Climatic Testing Machine (AUTO-2011)

Name: IEC60068-2-1 Xenon Lamp Climatic Testing Machine (AUTO-2011)
Brand: china-manufacturer-directory.com
SKU: 731783335
Availability: InStock
Rating: 4.5 (27 reviews)

Supplier:	Shenzhen Autostrong Instrument Co., Ltd.
Price:	US $ 3500-4500/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CIF,EXW

Product Specifications

Prod Model:	AUTO-2011
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name:	Xenon Lamp Climatic Testing Machine
Brand:	Autostrong
Delivery:	5~15 Working Days
Certificate:	CE, RoHS, ISO
Material:	Stainless Steel
OEM/ODM:	Acceptable
Warrantly:	One Year
Type:	Heating Type

Product Description

Xenon lamp climatic testing machine

Standard: IEC60068-2-1.1990 low-temperature testing method
IEC60068-2-2.1976 high-temperature testing method
GJB150.3 high-temperature test
GJB150.4 low-temperature test
GJB150.9 humidity test

Description:

Xenon lamp climatic testing machine is a comprehensive climate testing machine, can do climatic aging test and the lightfastness test of polymer materials which exposed at simulated sunlight. It simulates the light, temperature, rainfall, condensing, humidity to test the materials; It can be used for choosing new materials, improving existing materials, or assessment of change in material composition.

Application:

Xenon lamp climatic testing machine applied to control the product quality, such as electronic, plastic products, electrical appliances, instruments, food, vehicles, metals, chemicals, building materials, aerospace, medical care and so on.

Our products include: Glow wire tester, Needle flame tester, horizontal and vertical burning tester, tracking tester, textile burning tester, Xenon Lamp Climatic Chamber, melt dripping tester, building materials flammability tester, friction tester, test finger, spring hammer, universal testing machine and other testing instruments.

Please feel free to contact us if you are interested in our products. We'll be very happy to give your the best quotation on your detail requirements.

Testing room D×W×H		500600500mm
index	Temperature range	RT+10°C~80°C
	Humidity range	65~98%R@H
	Spray time	1~9999min, a d justable
	Spray cycle	1-240min, interval adjustable
	spectral wavelength	290nm~800nm(550w/m2)
	light source	climatic testing chamber
	Xenon lamp power	2.5 kw(longevity:1600H)
temperature and humidity control system	Time controller	Import controller from Moeller
	Accurate range	Temperature: ±0.1°C,/ humidity: ±0.1°CR@H
	Sensor	Platinum resistance Pt100Ω/mv
	Heating system	Independent system, nickel chromium alloy electric heating type heater
	Humidity system	stainless steel, external Isolated humidifier
	Blackboard temperature	Bimetal thermometer blackboard 55°C~75°C
	Water supply	Humidification water supply with automatic control, xenon lamp cooled by water recycling
	Temperature controller	Import controller
	humidity	Irradiation: 30%~65%RH darkly: up to 90%RH
	Cycle system	low-noise air-conditioning-type motors, multi-leaf-type centrifugal wind wheel
material	Outside material	Advanced spray color plate /SUS304 stainless steel
	Inside material	SUS304 stainless steel
	Sample holder material	SUS304 stainless steel
	insulation	High and low temperature aging of silicone rubber
standard		a set of radiation-proof glass window, dynamic testing sample shelf 1, xenon lamp tube 2
protector		Leakage, short circuit, over-temperature, water shortages, motor overheating, over-current protection.
Power		AC380V±10% 50±0.5HZ , Three-phase five-wire system
Environmental temperature		±5°C~+30°C ≤85%R@H
