Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Interactive whiteboard
Portable interactive whiteboard
Electronic whiteboard
Convert any board into interactive whitebard
Portable interactive whiteboard
Electronic whiteboard
EduBoard P3000 is not only an interactive whiteboard which needs a projector or a DLP display to work with, but also a digital copy board with which you can save, print, e-mail and on-line share what you write/draw on a conventional whiteboard or glass board using a whiteboard pen/marker when a projector is not available in classroom.
EduBoard P3000, not only an Interactive white board, but also a digital Copyboard!
Features of interactive whiteboard P3000:
1. Pens use long-lasting lithium watch batteries.
2. EduBoard software has unlimited user licenses.
3. Mounting brackets for portable or permanent setup.
4. Integrates seamlessly into your existing workflow.
5. Portable EduBoard receiver attaches to any standard whiteboard up to 9 feet by 3 feet.
6. Interactive Whiteboard
P3000 Can convert existing blackboard, whiteboard or DLP without extra budget for remodeling classroom and shaping board frame into standard interactive whiteboard.
Digital Copyboard
Can use with or without a projector. Everything written on the white board is automatically captured on your PC for further editing or distribution.
EduBoard sleeves accommodate standard dry erase markers found in every office supply store.
Collaborate and host whiteboard sessions with remote users, brainstorm interactively over the local intranet or Internet and share your ideas in real-time.
Playback feature allows you to rewind and replay all drawings on the board including erased items.
Copy and paste written notes into most popular office applications.
Capture your notes in color and save or send them in many different file formats.
Accessories of portable interactive whiteboard P3000
One EduBoard receiver
Receiver
One interactive stylus.
Stylus
One digital eraser.
Digital eraser (1)
One EduBoard marker pen sleeve.
P3000
CD with EduBoard software for PC, with product documentation.
15feet (5m) USB cable
USB2
Two mounting brackets.
DSC01923DSC01920
|
Receiver |
Receiver Fixing |
♦ Magnetic cup: Attaching the Mounting bracket with the magnetism.
♦ Suction cup: fasten the Receiver by suction cups.
♦ Command adhesive: To remove the suction cups and plaster stickup adhesive
♦ Screw: To permanently fasten the receiver |
|
Weight & Size |
Weight: 80g
Size30mm*130mm |
|
Power Supply |
Only USB Power supply and the LED indicator light to work |
|
Interactive stylus |
Mouse Function |
♦ Pen Tip: Left mouse function
♦ Button A: Right mouse function
♦ Button B: Interact Palette Tools |
|
Interactive Stylus Function |
By clicking B button to switch form the four different work mode; Mouse Mode, Blackboard Writing Mode,
Desktop Annotation Mode and PowerPoint Mode. |
|
Interact Palette Tools |
Can be shown, hidden, and dragged at any point any time. |
|
Power Supply |
One AA battery only. |
|
USB Cable |
Connect the EduBoard Receiver and computer. |
|
Capability |
Valid size |
Min: 20-inch; Max: 110-inch. ( diagonal) |
|
Surface compatible |
Normal whiteboard, Blackboard, LED Screen, Plasma, Rear Projection and even Wall. |
|
Software |
♦ Make annotation upon the interface of any other third party software, change color, thickness, width and shape.
♦ Save all the elements as the format of *PDF,*JPEG,*TIFF,*BMP,*HTML and print out on upload.
♦ Spotlight, Snapshot, Recorder, Handwriting Recognition, and PowerPoint annotation.
♦ Be compatible with Microsoft NetMeeting and Live Meeting. |
D-Rate (Beijing) Technology Co. Ltd is a global provider of seamless collaboration technologies and products for the education, distance learning, presentation, audio/visual conferencing, and office application markets. Founded by one former Intel R&D director and other experts in product development, manufacture, sales, business and finance, D-Rate has been recognized for its capability to solve complicated technical problems, bring innovative ideas into commercial quality products and focus on customer needs. Headquartered in China Silicon Valley -- Zhongguancun, D-Rate commits to offering home-grown innovations, leading-edge core technologies, reliable quality, competitive price and prompt after-sales service to world-wide customers.
With the break-through ultrasonic-infrared positioning technology, D-Rate mass produced its digital whiteboard products in 2007.
For education market, EduBoard™ Portable interactive whiteboard can upgrade, in conjunction with a digital projection, your existing flat surface into interactive whiteboard within few minutes.
ThinkBoard™ Is a brand of D-Rate's digital copy board products for corporate market, which can work with existing writing surfaces to capture meeting notes as they are created or real-time share with people all over the world.
Based on D-Rate's embedded components, OEM customers can assembly their own cost-effective embedded interactive or copy whiteboards with traditional whiteboard.
D-Rate is also looking for industry partners to incorporate the technology into compelling new interactive presentation and display products.
With customer orientation as one key corporate values, D-Rate offers 5-year warranty for all its products, quick response (within eight working hours), fast delivery (one week at most), effective custom clearance process and third party credit guaranty program.
