Features
Used to control time sequence
Toggle switch, various selection modes
Small size
Type |
Relay type |
JSz8 |
Voltage |
DC12~48V, AC12V~380V |
Delay range |
01, 02, 03, 04, 05 |
Operating type |
A: On delay 2C C: Instant F: Off delay
K: Off delay R: Circle delay G: Delay
V: Wide range |
Relay type |
Y: Star delta delay X: Thyristor output |
|
Specification |
Voltage |
AC/DC12~48V, AC24V~380V 50Hz/60Hz |
Power Expend |
DC1.0W, AC1.0VA |
Control Output |
5A 220VAC |
Insulation Resistance |
DC500V,100mΩ |
Dielectric Strength |
BCC1500VAC, BOC1000VAC |
Operating Temperature |
-10°C~50°C |
Humidity |
35%~85% |
Life |
Mech:106,Elec:105 |
Weight |
≈100g |
|
Time Range |
ASZ8-01 |
0.1-1S/1M |
ASZ8-02 |
0.5-5S/5M |
ASZ8-03 |
1.0-10S/10M |
ASZ8-04 |
3.0-30S/30M |
ASZ8-05 |
6.0-60S/60M
|
