Jzj-8000 Water-Based Spray Booth with High Quality

Name: Jzj-8000 Water-Based Spray Booth with High Quality
Brand: china-manufacturer-directory.com
SKU: 726077345
Availability: InStock
Rating: 4.3 (121 reviews)

Supplier:	Jiangsu Jingzhongjing Industry Coating Equipment Co., Ltd.
Price:	US $ 6000-12000/Set
Min Order:	1/Set
Quantity::
Trade Terms:	FOB,CFR,EXW

Product Specifications

Prod Model:	JZJ-8000
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	Sea Blue, Red, Orange, White
Paint Mist Treatment:	Dry-type
Heating Mode:	Diesel
Airflow Direction:	Fully Undershot-type
Certification:	ISO9001
Condition:	New

Product Description

1. We supply 24 months quality warranty spray booth.
2. JZJ provide you the best design spray booth.

Outside Dimension (mm)	7006 * 5656 * 3450(LWH)	Inside Dimension(mm)	6900 * 4000 * 2650(LWH)
Front Door(mm)	30002600 (WH)	Service door (mm)	1800650(WH)
Total Power	16.5KW
Cabin system	Wall panel	50mmEPS panel, double face steel sheet thickness: 0.6mm
	Ceiling panel	Galvanized steel sheet
	Basement	300mm depth, middle with grids, two side with checkered plates
	Ramp	three 2000*900mm ramps
	Glass	6mm safety tempered glass
	Windows	Square glass Windows
Air Make-up System	Air Inlet fan system	1 * 7.5kw turbo fan, proof-explosion motor, Ex rated
	Exhausted fan system	1 * 7.5kw turbo fan, proof-explosion motor, Ex rated
	Ai capacity	25000m3/h
	Air Flowing speed	0.3m/s in empty booth
	Air Control method	One manual damper for air inlet and exhausted system
	Exhausted ducting	8 meters air duct, one flop damper and one weather hood
Purification System	Pre-filter	G3 grade. Pockets filter.
	Ceiling filter	EU5 / F5
	Floor filter	green fiber glass filter / G3 grade
	Exhausted fan Filters	Pocket filter or M green fiber glass filter.
Heating System	Heat Exchanger	SUS304 material, argon arc welding.
	Heating burner:	Riello G20 diesel oil burner(gas burner for option)
	Heating productivity	180000Kcal/h
	Spray to baking switch	20N BELIMO brand electrical damper
	Chimney ducting	3 meters stainless ducting and one chimney elbow
	Max heating temperature	80degrees
	Heating time	4-6min(20-60degrees)
	fuel consumption	5-6Litters /vehicle
Lighting System	Ceiling lights	8 Units, each 4 x 36W Philips lamps, Total 1152 W
	Side lights	For option
	Illumination	1000LUX
Controlling system	Switched control panel	Spraying & baking switch, lighting switch, emergency stop, breakdown alarm, failure alarm, pressure gauge

Jiangsu Jingzhongjing Industrial Paint Equipment Co., Ltd, is located in the Yangtze River Delta Economic Zone, China Industrial Painting Base, Yancheng city, Jiangsu Province. We have the plant area of 99000m2, garden-style industrial zone. We have the staff of 260, including 20 engineers with 15years designing experience. Our annual production capacity can achieve 2, 500 sets paint booth.
We adhere to the "heritage of big business style, classic gaming counterparts, - creating the world brand" core values. Pursuit high goals, has won wide recognition and praise from the government and the market.
Our products are JZJ Brand spray booth, sandblasting booth, shot blasting machines etc. our products have passed the ISO9001, EU CE, the products have been shipped in the domestic 34 provinces and more than 50 countries like Germany, Japan, Russia etc.
Our products are well-known in the industrial of the automobile, aviation, military, wind power, nuclear power, engineering machinery, machine tool manufacturing, and other industries.
Welcome the customers from China and all over the world to join us!
