Kitchen Roll Tissue Packaging Machinery

Product Specifications

Prod Model:	TP-R200SD
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Stable Product Speed:	150 Rolls /Min
Packaging Type:	Bag
Type:	Automatic Wrapping Machine
Driven Type:	Electric
Automatic Grade:	Automatic

Product Description

A. Scope of application: Roll toilet/kitchen/household paper/tissue. It automatically achieve processes from feeding, packing to side sealing. So that it prevents the second pollution from hand operation.
B. Four servo control system making packing processes precise and stable.
C. Large PLC human-machine interface is easy for operation.
D. The transmission system mainly is made up of synchronous belt wheels and chains, which is easy for maintain.

Special functions:
A. Prevent air pack function saves waste and reduce cost. If there are no rolls, main machine automatically stops; When rolls come in, machine automatically runs. Thus you can save packing material and cut down production cost.
B. Prevent cutting rolls function. Machine has self-detection system. If rolls are misplace, machine automatically stops so that knives cann't cut them. Thus you save rolls paper and reduce cost.
C. Electric self-adjust cutting knife speed function. You don't need to adjust speed by your hand. It's very safe and conveinent.
D. The machine is both for cored rolls paper and non-cored rolls paper.
E. This machine stably packing rolls at 150 packs per minute in production field.

Name	Description	Remarks
Model	TP-R200SD
Toilet rolls diameter	80mm-125mm	Standard
Toilet rolls length	80mm-160mm	Standard
	160mm-260mm	Customize
Max mechanical speed	240 packs/min
Max stable production speed	200 packs/min
Machine dimension	7200mm*1200mm* 1680mm	Standard
Machine weight	1500kg
