LC1-F Series High Quality AC Electrical Contactor with CE
| Price: |
US $ 28-50/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Paypal,Money Gram,Western Union |
Product Specifications
| Prod Model: |
LC1-F, CJX2-F |
| Markets: |
North America,South America,Eastern Europe,Africa,Oceania,Western Europe |
| Brand: |
Winston |
| Colour: |
White Gre |
| Rial: |
Plastic Sil |
| Manufacturer: |
OEM |
| Condition: |
Original New |
| Size: |
Miniature |
| Usage: |
Household Appliances Relay, Communication Relay, Lathe Relay |
| Theory: |
Magnetic Contactor |
Product Description
Application CJX2 series AC Contactor is suitable for using in the circuits up to the rated voltage 660VAC 50Hz or 60Hz, rated current up to 95A, for making, breaking, frequently starting & controllingthe AC motor. Combined with the auxiliary contact block, timer delay & machine-interlockingdevice etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter. With the thermal relay, it is combined into the electromagnetic starter. The products comply withIEC CJX2-F AC contactor is suitable for using in the circuits u to the rated voltage 380V AC 50Hz, current 800A, for long distance breaking circuit and frequently starting or controlling the motor. Italso can be sed for the conntrol of distribution circuits of rated current from 200A to 1500A. Itconforms to IEC60947-4-1.60947-4.Dimension
Technical data| Type | Rated operational current in AC-3(A) | Max power ratings of 3-phase motors in category AC-3(kW) | Operating frequency (time/hour) AC-3 | Electrical life AC-3 x104 | Mechanical life x104 |
| 220V 230V | 380V 400V | 415V | 440V | 500V | 660V 690V | 1000V |
| CJX2-F115 | 115 | 30 | 55 | 59 | 59 | 75 | 80 | 65 | 1200 | 120 | 1000 |
| CJX2-F1154 | 115 | 30 | 55 | 59 | 59 | 75 | 80 | 65 | 1200 | 120 | 1000 |
| CJX2-F150 | 150 | 40 | 75 | 80 | 80 | 90 | 100 | 65 | 1200 | 120 | 1000 |
| CJX2-F1504 | 150 | 40 | 75 | 80 | 80 | 90 | 100 | 65 | 1200 | 120 | 1000 |
| CJX2-F185 | 185 | 55 | 90 | 100 | 100 | 110 | 110 | 100 | 600 | 100 | 600 |
| CJX2-F1854 | 185 | 55 | 90 | 100 | 100 | 110 | 110 | 100 | 600 | 100 | 600 |
| CJX2-F225 | 225 | 63 | 110 | 110 | 110 | 130 | 129 | 100 | 600 | 100 | 600 |
| CJX2-F2254 | 225 | 63 | 110 | 110 | 110 | 130 | 129 | 100 | 600 | 100 | 600 |
| CJX2-F265 | 265 | 75 | 132 | 140 | 140 | 160 | 160 | 147 | 600 | 80 | 600 |
| CJX2-F2654 | 265 | 75 | 132 | 140 | 140 | 160 | 160 | 147 | 600 | 80 | 600 |
| CJX2-F330 | 330 | 100 | 160 | 180 | 200 | 200 | 220 | 160 | 600 | 80 | 600 |
| CJX2-F3304 | 330 | 100 | 160 | 180 | 200 | 200 | 220 | 160 | 600 | 80 | 600 |
| CJX2-F400 | 400 | 110 | 200 | 220 | 250 | 257 | 280 | 185 | 600 | 80 | 600 |
| CJX2-F4004 | 400 | 110 | 200 | 220 | 250 | 257 | 280 | 185 | 600 | 80 | 600 |
| CJX2-F500 | 500 | 147 | 250 | 280 | 295 | 355 | 335 | 335 | 600 | 80 | 600 |
| CJX2-F5004 | 500 | 147 | 250 | 280 | 295 | 355 | 335 | 335 | 600 | 80 | 600 |
| CJX2-F630 | 630 | 200 | 335 | 375 | 400 | 400 | 450 | 450 | 600 | 80 | 600 |
| CJX2-F6304 | 630 | 200 | 335 | 375 | 400 | 400 | 450 | 450 | 600 | 80 | 600 |
| CJX2-F780 | 780 | 220 | 400 | 425 | 425 | 450 | 475 | 40 | 600 | 80 | 600 |
| CJX2-F7804 | 780 | 220 | 400 | 425 | 425 | 450 | 475 | 450 | 600 | 80 | 600 |
| CJX2-F800 | 800 | 250 | 450 | 450 | 450 | 450 | 470 | 450 | 600 | 80 | 600 |
Model meaning![]()
Detail![]()
![]()
![]()
