Price: | US $ 500set |
---|---|
Trade Terms: | FOB,CFR,FCA |
Min Order: | 1sets |
Pay Type: | T/T |
Part Number
HERO-IDS4F-8S
Resolution
32(H)×16(V)
Pixel Pitch
8mm
LED Configuration
1R1G1B 3-IN-1 SMD
Pixel Density
10,000pixels/ m2
Module Size
320*160mm
Driving IC
MBI5024
Driving Method
1/4 Scan, Constant Current
Cabinet Weight
42kg/sq.m.
Mechanical Ratings
Hanging Weight Support
2T
Surface Flatness
Gap<0.5mm
Optical Ratings
Brightness
>1,800cd/ m2
View Angle
150°/150°
Gray Scale
8bits input, correction with 14bits
Display COLOR
16.7M
Brightness Adjustment
0~100%
Power Supply
Operation Power
90~260V 50~60Hz
Max. Power Consumption
600W/ m2
Average Power Consumption
200W/ m2
Control System
Control Mode
Synchronous display with control PC by DVI
Frame Update Frequency
60~85Hz
Screen Refresh Frequency
300~1000Hz
Gamma Correction
-5.0~+5.0
Support Input
Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance
Ethernet cable<120m or Fiber Optic<10Km
Support VGA Mode
1024×768, 1280×1024, 1600×1200, 1920×1280
Brightness Correction
Pixel, Module, Cabinet
Environmental
Operating Temperature
-20°~+60°
Operating Humidity
10~95% RH
Operating Life
100,000hours
MTBF
5000hours
Protection Level
~
Out of Control Rate
<0.02%
Prod Model: | P3 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Lifespan: | 100,000hours |
Warranty: | 2 Years |
Tube Chip Color: | Full Color |
Display Function: | Video Display |
Pixel Configuration: | 1R,1G,1B |
Scanning Mode: | 1/8 Scan |
Display Type: | LED Video Display |
Application: | Shopping Guide |
Certification: | CCC |
Pixel Pitch: | 8mm |
Pixel Density: | 15625dots/Sq.M |
