Product Specifications
| Prod Model: |
LF + HF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
Cr80 |
| Frequency Of Chips: |
Lf + Hf |
| Function Of Card: |
Both of Lf or Hf |
| Origin Of Card: |
Shenzhen,China |
| Large Capacity: |
Competitive Price |
| Function: |
Information |
| Material: |
PVC |
| Frequency: |
Hf + UHF |
Product Description
LF + HF RFID hybrid card specifications
1.Dimensions: 86 x 54mm
2.Thickness:0.8=+_0.03mm
3.Material: PVC
4.Chip optional:Mifare TK4100+Mifare 1k S50,T5577 + F08
5.Frequency:13.56Mhz,125khz
6.Standard:ISO18000-6C/ISO14443A
7.Memory:32bits TID, 240bits EPC Number, 512bit user memory; 1k byte for Mifare
8.Working mode:read/write
9:Reading distance:10cm for HF or LF
10.Card Surface: Matt or glossy finish
11.Magnetic Stripe Option: 300oe, 2750oe, 4000oe
12.Housing: Lamination card
13.Operating Temperature: -20 to +60°C
14.Stockage Temperature: -20 to +65°C
Printing of RFID Card:
1.Full color offset printing
2.Silk-screen printing
3.Metallic gold/silver
4.Spot colour
Optional request of RFID Card:
1.Barcode:EAN13,code 39,code 128,etc
2.Jet dot numbering:black colour
3.Thermal printing number(black or silver colour)
4.Encoding upon requirement
5.Magnetic strip:300oe,2750oe,4000oe
6.Signature panel: white or transparent
7.Scratch panel(pin code)
8.Laser printing UID number
Application:
Public transportation, Access management,membership ID card,key card,employee card,
Event ticketing, Gaming Identity, club visiting, advertising, lottery, retail shop or store
insurance policy, super market, medical care, bank, parking, school. etc
Name: |
Contactless LF+HF Hybrid Card |
Material: |
PVC, PET, ABS |
Size: |
85.5*54*0.84mm |
Thickness: |
From 0.6mm to 2mm, standard thickness 0.76mm |
Minimum QTY: |
500pcs |
Processing: |
4 color offset printing, magnetic stripe, embossing number, signature panel, photo,barcode, hot stamping, gold / sliver color, scratch-off, series number, hole punching, spot UV printing, hologram, etc. |
Applications: |
membership,payment,tracking,access control,etc
|
Payment terms: |
By T/T or Western Union. 100% full advance payment of the total amount before production. |
Production time: |
8-12 working days after receipt of 100% advance payment (below 50,000pcs) |
Delivery: |
By sea or air express |
Packaging: |
For standard size cards:
Inner box: 22.5 * 9.3 * 6cm (250pcs / per box)
Carton: 52.5* 22.5 * 15cm (5,000pcs / per carton) |
Certification: |
ISO,SGS,ROHS |
Chips available:
Available |
125KHz |
|
|
ISO7815 |
EM4100 / H4100 |
64 Bits |
EM4102 / H4102 |
65 Bits |
EM4200 |
64 Bits |
TK4100 |
64 Bits |
EM4105 |
65 Bits |
EM4305 |
512Bits |
EM4450 |
1024Bits |
ATA5577 |
330Bits |
Hitag2 |
256Byte |
Hitag S 256 |
257Byte |
13.56MHz |
|
|
ISO / IEC 14443 A |
MF 1K S50 / MF1 S50 |
1KB |
MF4K S70 / MF1 S70 |
4KB |
MF Plus S2K |
2KB |
M Plus S4K |
4KB |
MF Ntag203 |
168Byte |
MF Ultralight |
64Byte |
MF Ultralight c |
192Byte |
MF DesFire EV1 8K(MF3 IC D81) |
8KB |
MF DesFire 4K (MF3 IC D40) |
4KB |
MF DesFire EV1 4K (MF3 IC D41) |
4KB |
ISO / IEC 14443 B |
SRI512 |
512KBit |
ISO / IEC 15693 |
I.code SLI SI2 / I.code 2 |
1KBit |
I.code SLI-S |
2048Bit |
I.code SLI-L |
512Bit |
Tag-IT Ti2048 |
2KBit |
Tag-IT Ti256 |
256Bits |
868MHz /915MHz: |
|
|
ISO18000-6B |
UCODE HSL, |
2048Bits |
ISO18000-6C & EPC Gen2.0 |
UCODE EPC Gen 2 |
512Bits |
UCODE GEN2 XL |
240Bits |
UCODE GEN2 XM |
880Bits |
XRA000, XRA Gen 2, ATA5590 |
|
ALIEN H3 |
96 - 480 Bits |
Impinj Monza3 |
96 Bits |
EM4324 , EM4444, EM4033, EM 4133 |
|
We, Sails RFID Smart Card Technology Co., Limited, focus on the manufacture & sale of LF/HF/UHF RFID label/tag, contact/contactless smart cards, plastic/paper cards, and card related products.
Our main products are: Contact/contactless smart cards with original chip or Chinese compatible chip, PET/paper RFID label, RFID dry/wet inlay, RFID wristband/keytag, NFC tag, one-time use microchip for animal ID, epoxy tag, smart cards inlay, membership VIP cards, gift cards, discounting cards, magnetic stripe cards, barcode/QR code cards, scratch cards, 3D lenticular cards, ID photo cards, un-standard snap off cards, etc. Our products are widely used in smart city constructure, public trsnsportation, supply chain logistics, warehouse asset management, anti-theft, animal ID tracking, campus/community access control, shop chain/club/hotel membership management, and etc. We have provided many clients both at home and abroad with millions of smart cards & RFID, plastic cards, and card related products. Such as paper/plastic card holder, card book, card/RFID reader and etc.
We have advanced card manufacture machine. Such as 5 color Heidelberg offset printer, 2 high-precision production lines for RFID label/inlay, 3 production lines for smart cards, plastic cards(please check details in Equipments). And we have dust-free workshops which reach ISO standard with 24 hours CCTV monitoring.
We are experienced in developing, production & sale of smart cards, RFID & plastic/paper cards. Very competitive price and large daily capacity are our advantages.
Seeing is believing. You are warmly welcome to visit our company. We are sure that you will be satisfied with our good products and our good service. Finally, you will be happy with long-term co-operation with us.
