Qingdao Desiree Group Rubber Machinery Co., Ltd. >> Long Using Life High Performance Tire Forming Vulcanizer

Long Using Life High Performance Tire Forming Vulcanizer

Name: Long Using Life High Performance Tire Forming Vulcanizer
Brand: China-Manufacturer-Directory.com
SKU: 688905472
Availability: InStock
Rating: 4.6 (90 reviews)

Supplier:	Qingdao Desiree Group Rubber Machinery Co., Ltd.
Price:	US $ 202000-252000/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CIF

Product Specifications

Prod Model:	LL-B1525 x 2(63.5")
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name:	Tire Forming Vulcanizer
Mould Quantity:	2
Steam Dome Internal Diameter:	1525mm
Max. Closing Force:	4220X2kn
Mould Height:	254-635mm
Applicable Bead Diameter:	19''-24''
Main Motor Model/Power:	LG41-6/16kw
Temperature Transmitter:	Jumo
Pressure Transmitter:	Jumo
Warranty:	One Year After Commissioning
Certification:	CE, ISO

Product Description

Long Using Life High Performance Tire Forming Vulcanizer / Tire Curing Press

Function:
1. For curing of all-steel heavy-duty radial tires.

2. For curing of semi-radial passenger car/light truck tires.

3. For curing of nylon bias tires with one set of additional post cure inflator.

Features:
1. The machine is multi-link type.

2. Mainly consists of main machine, center mechanism, mechanic claw, steam dome, segmented mould controller, tire stripping machine, unloader, cooling roll way, driving water piping, steam piping, force measure device, lubricating system, electrical control syetem, compressed air piping, safety device, top link centering device, etc...

3. Center mechanism type: B type.

4. Top link moving type: Two kinds, sliding back and tilting back

FOR PIPING, WE CAN DESIGN AS PER YOUR REQUIREMENTS.

Advantage:
1. High running stability.

2. Long using life with suitable maintance.

Our Services:
1. One year warranty after commissioning, and lifetime technical support.
2. Any demand, we will give feedback within 24hours.

FAQ:
Payment:
1. T/T 30% deposit, balance before shipment.
2. Negotiable.

Contacts:
Telephone & Fax: 86-532-84130227
Mobile Phone: 18560603872

If you have any question about our products, please feel free to contact with me.

Welcome to make a field inspection of our factory.

Tire Vulcanizing Machine Model No.	LL-B1525×2 (63.5")	LL-B1640×2 (65.5")	LL-B1310×2 (55")	LL-B1220×2 (48")	LL-B1145×2 (45")	LL-B1050×2 (42")
Steam dome specifiction(mm)	1525	1640	1310	1220	1145	1050
Max mould closing force (kN)	4220	4500	2890	1920	1720	1320
Mould height(mm)	254-635	254-635	245-445	305-505	230-455	180-300
Main motor power(kW)	16	16	13	11	11	11
Apply bead specification	19''-24''	19''-24.5''	16''-20''	13''-20''	12''-17.5''	12''-16''
Notes	Works for the vulcanization of TBR , PCR tires or bias tires.
	If it works for curing the bias tires, the press will match with post curing inflator.
	If works for curing the radial tires, the press will match with segmented mould controller.
