| Prod Model: | As arranged |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: | Passenger Elevator |
| Capacity: | 500-1000kg |
| Speed: | Middle Speed |
| Persons: | 10-19 |
| MODEL | Persons Fixed | Loding Weight | Speed (m/s) | Inner Size | Dooropen Net. Size (mm) | Hoist-Way (mm) | Top. Floor Height (mm) | PitDepth (mm) |
| ZFTKU630 | 8 | 630kgs | a=1.0m b=1.5m c=1.75m | 1400*1100 | 800*2100 | 2250*2000 | a=4200 b=4500 c=4700 | a=1600 b=1700 c=1800 |
| ZFTKU800 | 10 | 800kgs | a=1.0m b=1.5m c=1.75m d=2m | 1400*1350 | 800*2100 | 2250*2150 | a=4200 b=4500 c=4700 d=5000 | a=1600 b=1700 c=1800 d=2000 |
| ZFTKU1000 | 13 | 1000kgs | a=1.0m b=1.5m c=1.75m d=2m | 1600*1500 | 900*2100 | 2450*2250 | a=4200 b=4500 c=4700 d=5000 | a=1600 b=1700 c=1800 d=2000 |
| ZFTKU1250 | 16 | 1250kgs | a=1.0m b=1.5m c=1.75m d=2m | 1750*1600 | 1000*2100 | 2700*2400 | a=4200 b=4500 c=4700 d=5000 | a=1600 b=1700 c=1800 d=2000 |
| ZFTKU1600 | 21 | 1600kgs | a=1.0m b=1.5m c=1.75m d=2m | 1800*1900 | 1000*2100 | 2800*2600 | a=4200 b=4500 c=4700 d=5000 | a=1600 b=1700 c=1800 d=2000 |
