| Prod Model: | As arranged |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Installation: | Roughterrain Wheeled Crane |
| Application: | Port Crane |
| Structure: | Boom Crane |
| Type Of Work: | Light Level |
| MODEL | Persons Fixed | Loding Weight | Rated Speed | Inner Size | Dooropen Net. Size (mm) | Hoist-Way (mm) | Machine Room (mm) | Top-floor height | Pit. Depth (mm) |
| ZFTG800 | 10 | 800kgs | 1.0m/s | 1300*1700 | 800*2100 | 2200*2300 | 3200*4500 | 4500 | 1550 |
| ZFTG1000 | 13 | 1000kgs | 1.5/1.6 | 1400*1900 | 900*2100 | 2300*2450 | 3200*4500 | 4600 | 1600 |
| ZFTG1150 | 15 | 1150kgs | 1.75ms | 1500*1900 | 900*2100 | 2400*2450 | 3400*4500 | 4700 | 1700 |
| ZFTG1250 | 16 | 1250kgs | 2.0ms | 1500*2050 | 900*2100 | 2400*2600 | 3400*5000 | 4800 | 1800 |
| ZFTG1350 | 18 | 1350kgs | 2.5ms | 1500*2150 | 900*2100 | 2500*2700 | 3400*5000 | 5000 | 2200 |
| ZFTG1600 | 21 | 1600kgs | 3.0ms | 1600*2200 | 1000*2100 | 2600*2700 | 3600*5000 | 5400 | 2500 |
| Loading Weight (kgs) | Motor Power / 1.0m/s | Motor Power / 1.5m/s | Motor Power / 1.6m/s | Motor Power / 1.75m/s | Motor Power / 2.0m/s |
| 450 | 3.2kw | 5.1kw | 5.1kw | 5.6kw | |
| 500-630 | 4.6kw | 6.9kw | 7.4kw | 8.1kw | |
| 800 | 5.5kw | 8.3kw | 8.8kw | 9.7kw | 11kw |
| 1000 | 6.7kw | 10kw | 10.7kw | 11.7kw | 13.4kw |
| 1150 | 8kw | 12.7kw | 12.7kw | 14kw | 16kw |
| 1250 | 8.6kw | 13.6kw | 13.6kw | 14.8kw | 1.7kw |
| 1350 | 9.4kw | 14.9kw | 14.9kw | 16.2kw | 18.5kw |
| 1600 | 11kw | 17.6kw | 17.6kw | 19.1kw | 21.9kw |
