Machinery with 4 Head Spindle, 1600*2500*200mm Working Size CNC Woodworking Machine

Product Specifications

Prod Model:	FCT-1625W-4S
Markets:	North America,Southeast Asia,Mid East
Machine Size:	1600X2625mm
Working Size:	1600X2500X200mm
Spindle Type:	Water Cooling
Spindle Power:	1500wx4
Motor:	Steppet
Operating System:	Ncstuido
Inverter:	Fuling
Guide Rails:	Taiwan PMI Linear Square Rails
Transmission:	Xy Gear Rack, Z with Tbi Ball Screw
Net Weight:	1300kg
Spindle Layout:	Horizontal
Feed Mode:	Mechanical
Controlling Mode:	CNC
Certification:	ISO
Type:	CNC Wood Relief Machine
Spindle Number:	4 Spindles

Product Description

Features:
1.       The lathe is founded by industrial pipe welding, box-type structure to ensure the high stablity.
2.       The special instruments to eliminate welding stress, high-precision machining planer ensure the precision and no deformation.
3.       The major machine body makes the stability and no shacking in high speed.
4.       XYZ all apply imported screw, high precision gear frame linear square guide, ensure the high accuracy.
5.       The professional mechanical design, scientific structure and generous appearance, gantry height 200mm can ensure Z axis working size.
6.       XYZ axis use anti-dust system, prevent dust during working, make sure the long lifespan of spare parts.
7.       High quality driver motors, spindle motors, cables, inverters,etc.
8.       Professional CNC control system, can compatible with many kinds CAM software, suc as TYPE3/ARTCAM/UG/PRO-E/MASTERCAM.

Application:
Widely used in Antique furniture with relief carving, wood carving, furniture-processing, instrument making, 3D light box making, Aluminum composite panel, funding mound decorative doors and windows processing etc.

Special configuration:
It can be customized more large format and special format models, and it can be optional standard configuration spindle or importing,oil lubrication system, vacuum inhaling and dust collect etc.

Technial Parameters:

Model	FCT-1625W-4S
Machine size	1600x2625mm
Working size	1600x2625x200mm
Spindle power	water cooling 1.5KWX4
Spindle rotation	6000~24000rpm
Motor driver	Leadshine hybrid servo motor
TOOL diameter	3.175, 4, 6mm
Machine structure	Industry square tube structure
Transmission	XY gear rack,Z TBI ball screw
XYZ rails	PMI square rails
Dust-proof system	XYZ high quality dust cover
Mechanical accuracy	less than 0.03mm
Engraving speed	8000mm/min
Data transmission	PC-connection directly or USB
Support format	G code or HPGL
Working voltage	AC220V/50Hz or 380V/50Hz
Net weight	1300kg

Good service:
1.Under normal usage, 1 year for the whole machine,lifelong technical support.
2.Free technical support for lifetime, including training at factory, door to door service, such as training/ installment/ adjustment / maintenance.
3.Door to door service, you just need to bear round-trip tickets and accommodation.
4.Free installation,testing,training before shipping.
5.Advice for the best solutions for your requirements.
