Mag-Strip Reader Magnetic Reader Module Series
Product Specifications
| Prod Model: |
HCC750M |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Conformance: |
ISO 7811 Conformance |
| Connector: |
9 Pin 2.54mm Molex or Customized |
| Card Operation Speed: |
10 ~ 120 Cm/Sec(210 Dpi) |
| Certification: |
CE |
| Type: |
Mag-Strip Reader Module |
Product Description
Feature
Low power consumption, CMOS for TTL electronic level.
ISO 7811 conformance.
Reading single, dual or triple tracks.
Small size.
Specification
| Single track | Dual track | Triple track |
| Current | 3.5 mA | 5.2 mA | 7.3 mA |
| Connector |
| 9 pin 2.54mm Molex or customized |
|
| Card operation speed |
| 10 ~ 120 cm/sec(210 DPI) |
|
| Voltage |
| 5V ±5% / 3.5V at optional |
|
| Decoding method |
| F/2F |
|
| Operation temperature |
| -10 ~ 50°c |
|
| Life time of head |
| Approx. 300,000 passes |
|
| Card standard |
| ISO 7811 |
|
| Dimension (L*W*H) | 90*21*25mm (45*21*25 mm at optional) |
| Cable length |
| 15 cm |
|
Model Description
750Mx1-x2x3
| Type | X1 | Interface | X2X3 | Tracks |
750M
Mag-strip Reader Module | T | TTL | 04 | 1&2 tracks |
|
| 05 | 2&3 tracks |
|
| 06 | 1&2&3 tracks |
|
|
|
|
|
|
|
|
For example
HCC750M T 06 -Mag-strip Reader Module, with TTL signal electronic level, triple tracks (1/2/3) reader module.
