Price: | US $ 215000/Set |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 1/Set |
Pay Type: | L/C,T/T |
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
---|---|
Model No.: | Ll-B1310*2 |
Steam Dome Specification: | 1310 Mm |
Max Mould Closing Force: | 2890 Kn |
Mould Height: | 245-445 Mm |
Bead Dia.: | 16"-20" |
Main Motor Power: | 13 Kw |
Type: | Tire Machinery |
Type Of General Rubber Machinery: | Material Processing Machine |
Type Of Tire Machinery: | Tire Shaping and Curing Press |
Weight: | 50~300 tons |
Certification: | CE, ISO, SGS |
Model | LL-B1640x2 (65.5") | LL-B1525×2 (63.5") | LL-B1310×2 (55") | LL-B1220×2 (48") | LL-B1145×2 (45") | LL-B1050×2 (42") |
Steam dome specification | 1640 | 1525 | 1310 | 1220 | 1145 | 1050 |
Max mould closing force | 4500 kN | 4220 kN | 2890 kN | 1920 kN | 1720 kN | 1320 kN |
Mould height(mm) | 254-635 | 254-635 | 245-445 | 305-505 | 230-455 | 180-300 |
Main motor power(kW) | 16 | 16 | 13 | 11 | 11 | 11 |
Bead Dia. | 19"-24.5" | 19"-24" | 16"-20" | 13"-20" | 12"-17.5" | 12"-16" |
Notes | Works for the curing of TBR, PCR tires or bias tires. If it works for curing bias tires, the press will equip with post curing inflator. If works for curing radial tires, the press will equip with segmented mould controller. |
