Product Specifications
| Prod Model: |
TPS-SW600 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Technical Parameters
Manifold
8pin and 12 pin
Mode
Strip mode and Plate mode
Strips
1-12 or 1-8(according to the manifold)
Dispense Volume
50-999ul(increase 5ul with progressively)
Aspiration time
1-99
Pause duration
Strip mode: 0-99minutes99seconds, Plate mode: 0-99minutes99seconds (increase 1 second with progressively)
Soak time
0-99minutes99seconds(increase 1 second with progressively)
Dwell time
0-99minutes99seconds(increase 1 second with progressively)
Prewash time
5-99seconds(increase 1 second with progressively)
Bottle volume
2L, 3pcs(Rinse bottle, Detergent bottle, Waste bottle), with liquid level Sensor
Residual Volume
2ul
Repeatability with charging Volume:
5%
With a fluid way
Dual pump Structure
Charging pump positive pressure
200Kpa
Imbibitions pump Negative pressure
60Kpa
Liquid Exhaust
Detergent: 50ml/plate; Prewashing: 15ml
Input power
150VA
Power supply
AC(110-240V) 50Hz/60Hz
Display
240X128 LCD(Touch screen)
Input mode
Touch with large screen, keyboard entry
Imbibitions speed
1-6grade(Select for free)
Imbibitions time
3-99seconds(increase 1 second with progressively)
Imbibitions Mode
Convention\Imbibitions with two point\Cleaning
Micro plate type
U/V/Flat style
Plate cut install
10 species
STBY
Automatic washing function(The standby state with channel)
Programe enable
Charging\Imbibitions\Dwell\Soak\Shake board\Circulate, sequential ganization with random order
Net weight
9.6Kg
Gross weight
12.5Kg
Volume(Instrument)
48cm× 33cm× 14cm
Outer box
51*45*48cm
