Product Specifications
| Prod Model: |
QX-4040 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Working Area: |
400*400mm |
| Cooling Mode: |
Water Cooling |
| Voltage: |
AC 110-220V |
| Automatic: |
Automatic |
| Type: |
Wood Process and Matching Equipment |
| Controlling Mode: |
CNC |
| Feed Mode: |
Mechanical |
| Spindle Number: |
Single-Spindle |
| Spindle Layout: |
Spindle Over |
| Certification: |
CE |
Product Description
Mini CNC Router Machine
1. Router machine1. Have high accuracy and working speed,？
2. Can engrave: Metal, glass, wood, marble, plastic, acryl, etc
Applicable to:？
Advertising signs, Logos and Brands, Acrylic Letters, part productions, Signs, tablets Calligraphy, architecture model, embossment, Home and Business decorations, Gardening decorations Wall decorations.？
|
Working Area X*Y*Z |
400*400*60mm(14.2*14.2*2.36 inch) |
|
Maxing Moving Speed |
5000mm(197inch)/min |
|
Max Engraving Speed |
3000mm(118.2inch)/min |
|
Reposition Accuracy |
0.02mm |
|
Spindle |
800w Water Cooling |
|
Transmission |
Imported Ball Screw |
|
Operation System |
DSP Controller |
|
Consumption Power |
< 450W |
|
Voltage |
AC220V/50Hz |
We are a serious supplier, and supply very good quality to our customers to keep ahead in the same filed. Just only one sample machine, you will find more surprised pleasure with own eyes. We guarantee everything under our inspection and control, including the selection of raw material, the research of the new technology and crafts, the inspection of production process, the packaging of the machines, the accurate and fast tech support.
QX Laser established long stable relationships with many famous universities and science and technology institutes in Shanghai and Beijing. Under the guidance of the scientific research team, QX Laser accomplished the whole processes from software exploitation, hardware design, and system detecting to technical supporting
