Features:
Product technical description
Specification: 30L~50000L
Material: SS316L or SS304
Surface finish: inside surface is Ra0.28~0.6μm by mechanical polish. (passivation or electropolish are optional). Outside surface is Ra0.6~0.8μm by satin finish.
Agitator: bottom magnetic agitator
Pressure: ATM or pressure vessel (-0.1~1Mpa)
Structure: Single layer vessel, vessel with jacket, vessel with jacket and insulation
Jacket type: dimple jacket, full jacket, or coil jacket
Insulation material: rock wool
Components: vent filter, temp. gauge, level gauge, manhole, sight glass with lamp and cleaning ball or according to client's detail requirement.
Manufacture standard for pressure vessel: ASME, PED 97/23/EC, GB150-2011
Working volume |
Inner diameter |
Outer diameter |
Vessel height |
Total volume |
30L |
400mm |
500mm |
400mm |
44L |
50L |
400mm |
500mm |
600mm |
69L |
100L |
500mm |
600mm |
650mm |
130L |
200L |
600mm |
700mm |
1000mm |
250L |
300L |
700mm |
800mm |
1250mm |
370L |
500L |
900mm |
1050mm |
1150mm |
650L |
1000L |
1100mm |
1250mm |
1480mm |
1260L |
1500L |
1200mm |
1350nmm |
1700mm |
1780L |
2000L |
1300mm |
1500mm |
1980mm |
2200L |
3000L |
1500mm |
1700mm |
2150mm |
3400L |
4000L |
1600mm |
1750mm |
2630mm |
4000L |
8000L |
1900mm |
2100mm |
3200mm |
8300L |
The above dimension is only for reference, we can make up to 50000L , and we can make special dimension according to client specific requirement. |
Prod Model: | RTCL |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Validation: | GMP, cGMP |
Documents: | GMP, Dq, Iq, Oq, Pq, Fat, Sat, Manual, etc. |
Certification: | Asme, PED 97/23/Ec, Nb, GB, ISO 9001:2008 |
Mixer Type: | Agitator |
Working: | High Speed Mixer |
Application: | Liquid |
Additional Capabilities: | Heating, Cooling, Temp. Control and Record |
