Motor Control Russian Type Silicon Control Rectifier

Name: Motor Control Russian Type Silicon Control Rectifier
Brand: China-Manufacturer-Directory.com
SKU: 663537921
Availability: InStock
Rating: 4.8 (95 reviews)

Supplier:	Yueqing Shangjing Rectifier Co., Ltd.
Price:	Negotiable/Piece
Min Order:	20/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	T153-2000-8
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Manufacturing Technology:	Logic IC
Material:	Element Semiconductor
Type:	Intrinsic Semiconductor
Package:	Standard Export Packing
Application:	Welding , Motor Soft Start
Model:	T153-2000-8
Batch Number:	2015+
Brand:	Shangjing

Product Description

Features
All diffuse techinics
Ceramic disc type seal
Middle trigger
Bi-facial cooled
High current

Typical Applications
Big power transformer
AC & DC motor control
AC & DC switch
Phase control rectification
Inverter
Welder

Explanation
IGT, VGT, IH are all TA=25° C test data, others are all TA=Tjm test data.
I2t=I2TSM× TW/2: TW=Half sine wave current, when at 50Hz, I2t=0.005I2TSM(A2S)
When at 60Hz, ITSM(8.3ms)=ITSM(10ms)× 1.066, Tj=Tjm I2t(8.3ms)=I2t(10ms)× 0.943, Tj=Tjm

Type	V_RRM	I_RRM	I_T(AV)	I_T(RMS)	I_TSM	V_TM/I_TM	di/dt	dv/dt	V_GT	I_GT	I_H	T_j	R_jc	t_q	M2	Wt	Outline
			Tc55° C	Tc70° C	10ms	25° C				25° C
	V	mA	A	A	kA	V/A	A/μ s	V/μ s	V	mA	mA	° C	° C/W	μ s	kN	kg
T123-200	400-1600	15	200	265	4.0	1.80/628	200	200-1600	3.5	250	≤ 200	-40 ~ +125	0.08	250	6	0.07	RC1 RC2
T123-250	400-1600	20	250	750	4.5	1.65/785	200	200-1600	3.5	250	≤ 200		0.08	250	6	0.07
T123-320	400-1600	20	330	1090	5.0	1.55/1005	200	500-1600	2.5	250	≤ 200		0.08	100-200	6	0.07
T123-500	400-800	30	500	550	6.0	1.40/1570	200	500-1600	2.5	200	≤ 250		0.07	63-125	6	0.07
T133-400	400-1600	30	400	935	8.0	1.65/1258	200	200-1600	2.5	200	≤ 250		0.045	250	10	0.18	RC2 RC3
T133-500	100-800	50	500	1720	10	1.40/1570	320	500-1600	2.5	150	≤ 250		0.035	160	10	0.10
T233-500	400-1800	30	500	1160	9.0	1.70/1570	200	500-1600	2.5	250	≤ 250		0.04	100-200	10	0.10
T133-600	100-800	50	600	2085	12	1.50/2512	200	500-1600	2.5	250	≤ 250		0.035	63-125	10	0.18
T133-630	100-1200	40	630	1430	12	1.55/1978	200	500-1600	2.5	250	≤ 250		0.04	80-160	10	0.10
T143-500	400-1600	40	500	1175	11	1.70/1570	200	200-1600	3.5	300	≤ 250		0.034	250	15	0.240	RC4 RC5
T243-500	1800-3200	40	550	1110	10	1.90/1570	200	500-1600	2.5	250	≤ 250		0.034	200-400	15	0.240
T143-600	900-1800	70	640	1250	9.0	1.85/1978	200	500-1600	2.5	250	≤ 300		0.032	160-320	15	0.240
T143-1000	100-1200	50	800	1585	14	1.60/2512	200	500-1600	2.5	250	≤ 300		0.032	100-200	15	0.160
T143-1250	100-800	30	1045	1860	19	1.50/3140	200	500-1600	2.5	250	≤ 300		0.030	80-160	15	0.160
T153-800	100-1000	50	800	1840	20	1.80/2512	200	200-1600	3.5	300	≤ 300		0.024	100-400	24	0.500	RC6 RC7
T153-1250	100-800	100	1250	3000	18	1.40/4000	300	500-1600	3.5	300	≤ 300		0.016	100-400	24	0.550
T153-1600	100-800	100	1600	3500	22	1.35/5000	300	500-1600	3.5	200	≤ 300		0.016	100-140	24	0.550
T253-500	5200-6000	150	530	1175	10	2.30/1570	100	500-1600	3.5	200	≤ 300		0.026	100-400	24	0.550
T253-800	2000-2400	70	800	1470	17	2.00/2500	200	200-1600	3.5	350	≤ 300		0.020	100-400	24	0.550
T253-1000	1000-1800	70	1000	2300	22	1.70/3140	200	200-1600	3.5	300	≤ 300		0.020	100-140	24	0.550
T253-1250	400-1800	70	1250	1830	28	1.50/3925	200	200-1600	3.5	300	≤ 300		0.018	100-140	24	0.550
T173-2000	1600-2000	200	2000	4600	49	1.55/6280	320	500-1600	3.5	300	≤ 300		0.011	100-140	24	1.200	RC8
T173-2500	200-2400	100	2700	5750	52	1.60/7850	200	500-1600	3.5	350	≤ 300		0.010	100-140	24	1.200
T173-3200	200-2400	200	3360	7360	60	1.40/10050	320	500-1600	3.5	300	≤ 300		0.010	100-140	24	1.200
T173-4000	200-2400	200	4000	9200	62	1.40/12560	200	500-1600	3.5	300	≤ 300		0.010	100-140	45	1.200

China Shangjing Rectifier Co., Ltd. Was co-founded by China DELIXI Group, Shanghai Rectifier Co., Ltd. And Jingtai Electric Co., Ltd. In 1999. As one of the most professional manufacturers of power semiconductors and silicon rectifying whole set equipments, our company has been devoted to provide the high quality semiconductor products for our customers all over the world.
Shangjing Rectifier Co., Ltd. is located in Liushi Town which is well known as the "Capital of Electric City" in China. We are very close to the Wenzhou Airport and the deep-water sea port, which makes it very easy for us to reach our customers from the whole world.

Our company has been certified by China Industrial Department and we have got CE certificate. Furthermore, our products are compliant to the latest RoHS directions.

We have brought advanced technologies and equipment from abroad and kept improving our management and products quality. We stick the spirit of "Chasing for high quality and Servicing our clients with all our heart and credibility", we have gained a lot of honors like "AAA class China quality & credibility company", "member of China Electric Industry Association", etc. We have been exporting our products to Europe, South and North America, Middle East, Africa and earned a lot of good feedback.

We hope our high quality products and service will be bringing successful future to all our customers.
