Product Specifications
| Prod Model: |
GR180 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Walking Mode: |
Wheeled |
| Condition: |
New |
| Certification: |
ISO9001: 2000 |
| Load And Unload Method: |
Rotary |
| Type: |
Motor Grader |
Product Description
Main Specification for the GR180 Motor Grader
GR180 Motor Grader Performance and Characteristic:
The design of new appearance.
The articulation frame is adopted and matched with the steering of the front wheel with small turning radius.
The electrio-hydraulic controls the power shift gearbox with 6 forward gears and 3 back gears.
The international matching hydraulic parts are adopted with reliable operation.
The motions of the blade are fully hydraulically controlled.
The rear axle is the three-section driving axle which is provided with the NO-PIN self-locking differential mechanism.
The manipulation table and seats are adjustable. The arrangement of the manipulation handle and instruments are reasonable, with convenient application and comfort of driving is improved.
The cab is grand and nice, with wide eyeshot and good sealing.
The front bulldozing plate, rear scarification device, front scarification harrow and automatic leveing device can be added.
|
Basic specification |
|
Engine model |
SC8D190G2B1 Engine |
|
Rated power/speed |
140kW/2300rpm |
|
Dimension(LxWxH) |
8900×2625×3470mm |
|
Operating weight(Standard) |
15400kg |
|
Performance specification |
|
Travelling speed ,forward |
5\8\11\19\23\38 km/h |
|
Travelling speed ,reverse |
5\11\23 km/h |
|
Tractive force(f=0.75) |
79KN |
|
Max. gradeability |
20% |
|
Tire inflation pressure |
260 kPa |
|
Working hydraulic pressure |
16 MPa |
|
Transmission pressure |
1.3~1.8MPa |
|
Operating specification |
|
Max. steering angle of front wheels |
±50° |
|
Max. lean angle of front wheels |
±17° |
|
Max. oscillation angle of front axle |
±15° |
|
Max. oscillation angle of balance box |
15 |
|
Frame articulation angle |
±27° |
|
Min. turning radius using articulation |
7.3m |
|
Blade |
|
Maximum lift above ground |
450mm |
|
Maximum depth of cutting |
500mm |
|
Maximum blade position angle |
90° |
|
Blade cutting angle |
28°_70° |
|
Circle reversing rotation |
360° |
|
Moldboard width X height |
3965×610mm |
Since 1990, Kudat Industry and Trade Company has exported engineering machinery, construction machinery and agricultural machinery to international markets. Satisfying customers' stated and implied needs have always been the focus of business policy of Kudat. As a further step to satisfy customers and to give them confidence in our quality & production capabilities, Kudat has adopted ISO 9001: 2000, the international quality management system. And some of our products have also passed CE and EPA certification.
With a rich inventory of numerous products and vast sourcing capabilities (more than 60 famous manufacturers) cater to the requirements of its customers. Except abundant of products, we also set up factory for studying and producing relative machinery products. From base to top, Kudat holds a unique position in the global market of machinery products which is combination of production and trade.
With 16 years experience in the export of machinery products, Kudat has gained reputation and confidence as a reliable Chinese supplier. By virtue of committed management and dedicated employees, Kudat has gained recognition from the government of China as an excellent exporter.
