Product Specifications
Prod Model: |
S102901 |
ISO9001:2008: |
Quality Management Qualification |
ISO/Ts 16949: |
Automotive |
ISO 13485: |
Medical Devices |
ISO 14001: |
Environmental Qualification |
Type: |
Flexible Circuit Board |
Dielectric: |
FR-4 |
Material: |
Paper Phenolic Copper Foil Substrate |
Flame Retardant Properties: |
V0 |
Product Description
1. Over 10 years'manufacturing experience focus on flexible circuit industry area.
2. Assembly provided.
3. 100% quality tested before shipment.
4. Certificate of UL, ISO9001, ISO14001 and ISO/TS16949.
5. Our Products meet the RoHS & WEEE lead-free requirement.
6. Small Order accepted.
7. 3 weeks for massive production; 10 days for sample since material prepared
Urgent case or spread delivery schedule will be updated per negociation then
FPC Apply:
medical apparatus
automobiles
aerospace
industrial equipment
detecting instruments
smart-home controller
consumer electronics, etc
Main Technique Index |
Description | Parameters |
Polyimide | Polyester |
Base film Thickness (um) | 12.5,25,35,50 | 12.5,25,35,50 |
Copper Thickness (um) | 12,17.5,35,50,70,105 |
Min. Line Width/Line Space (mm) | 0.075/0.075 |
Min. Hole Size (mm) | 0.15 |
Tolerance (mm) | Outline:+/-0.05; Coverlay: +/-0.2 |
Peel Strength (kgf/cm) | Above 1.0 | Above 0.8 |
Solder Resistance | 260C 10 seconds | 204C 5 seconds |
| | |
Surface Treatment |
Content | Normal coating thickness | Normal PNL size |
Plating nickel gold (In house) | Ni:2-9um;Au:0.03-0.09um | 300mm×400 MM |
Plating hard gold (In house) | Ni:2-9um;Au:0.1-1.0um | 300mm×400 MM |
Plating soft gold (In house) | Ni:2-9um;Au:0.03-0.09um | 300mm×400 MM |
Plating pure tin (In house) | 2.0-8.0um | 300mm×400 MM |
Immersion Tin (In house) | 0.3-0.6um | 300mm×400 MM |
OSP (In house) | N/A | 300mm×400 MM |
ENIG (Hard Nickel) (In house) | Ni:2-6um;Au:0.03-0.10um | 300mm×400 MM |
ENIG (Soft Nickel) (In house) | Ni:2-6um;Au:0.03-0.10um | 300mm×400 MM |
ENEPIG (Hard Nickel) (In house) | Ni:2-6um;Au:0.03-0.10um | 300mm×400 MM |
HASL (Outsource) | Cover the pads with min thickness 1~2 um | 300mm×400 MM |
Immersion silver (Outsource) | Per standand creteria | 300mm×400 MM |
