Om108 Slide Potentiometer

Name: Om108 Slide Potentiometer
Brand: China-Manufacturer-Directory.com
SKU: 689837522
Availability: InStock
Rating: 4.5 (69 reviews)

Supplier:	Yueqing Omter Electronic & Technology Co., Ltd.
Price:	US $ 0.5-1/Piece
Min Order:	1000/Piece
Quantity::
Trade Terms:	FOB,CIF,CIP

Product Specifications

Prod Model:	OM108
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Resistance Tolerance:	±20%
Rated Power:	0.05W 70 °c
Max. Operating Voltage:	50V
Operating Temperature:	-20°c~+85°c
1:	Long Life-Time
2:	SGS Certificate
3:	Eco-Friendly Raw Material
4:	Simply Installment
6:	OEM Welcomed
7:	for Printing Equipment
Resistance:	Variable Resistor
Type:	Slide Potentiometer
Installation:	DIP Resistor
Function For Resistance:	Protective Resistor
Material:	Carbon Film Resistor
Package Type:	Throught Hole

Product Description

1.High quality and reasonable price
2.Model NO : OM108
3.Slide potentiometer
4.MOQ: 10000pcs

Sample:

1. Sample: Could provide sample.

2. Samples time: Need 3-10 days to preparing the samples after receiving the payment.

3. Samples payment term: T/T, PAYPAL, Western union

Quality Guarantee:

1.Strictly quality control before leave factory

2. Quality guarantee within one year

Advantage:

1.Low MOQ: 10000pcs/ 1000pcs for other slide potentiometer

2.New design Accepted: As your requirement

3.Good Service: Customer as God

4.Good Quality: Strict quality control and good reputation

5.Fast & Cheap Delivery: Big discount from express agent (Long-term Contract)

Order Guide:

1. Inquiry-Professional quotation.

2. Confirm the price, lead time, packing requirement, payment term etc.

3. OMTER sales send the Proforma Invoice with OMTER seal.

4. Customer make the payment and send us Bank receipt.

5. Will inform client that we have got the payment, arrange the production & inform the estimated time.

6. After delivery will inform the tracking number and check the status for clients.

7. Feedback to TALL about Quality , Service, Market Feedback & Suggestion. And we can do better .

General Characteristics:	See drawing
Shape and dimensions	-10°C~+75°C
Operating temperature range	-20°C~+85°C
Test conditions	Ordinary temperature (5~35°C)
	Ordinary humidity (45~85°C)
	Ordinary atmospheric pressure (86~106kPa)
Certificate	ROHS Compliant
Mechanical Characteristics:
Slider Travel	8mm
Operating force	10~50gf.cm
Electrical Characteristics:
Resistance Range	Any resistance as customer request
Power rating	0.05W 70 °C
Max operating voltage	50V
Total Resistance error	±20%
Residual resistance:
Slider noise	≤68mV
Insulation resistance	50MΩ min @ DC100V
Withstand voltage	1 minute @ A.C100V
Solderability	235°C±5°C @ 3±1 seconds
Endurance:
Heat resistance	16 hours @ 85±2°C
Moisture resistance	No change after 16 hours at 85±2°C
Low temperature resistance	No change after 96±4 hours at 40±2°C and 90~95%Rh Loaded
Rotation life	10000 times ΔR≤25%R(Reciprocate 10,000 times at a speed of 10~15 times reciprocation per minute with no-load in the ordinary temp and humidity.)

LINP OMTER INTERNATIONAL HOLDINGS LIMITED, Including WENZHOU LINP TRADING Co., Ltd. And YUEQING OMTER ELEC&TECH COMPANY Ltd.

YUEQING OMTER ELEC&TECH COMPANY Ltd. Is a factory special in manufacturing knob, potentiometer and joystick and dealing with domestic business. WENZHOU LINP TRADING Co., Ltd. is responsible for the production of our company and various products of other companies import and export business.

Company have Strong technical force, with excellent supporting mold and injection molding equipment, professional technical personnel, with new product design, development and production capacity. Advanced production equipment, complete testing hand side, strict quality control, is a professional manufacturer of knobs.

Our TYXN knob according to the material difference. Have plastic knob, Bakelite knob, metal knob, aluminum knob and so on. According to the function difference. We have potentiometer knob. Radio push knob. Sound plastic components. Sound knob, dial knob, instrumentation knob. Electronic knob. Switch knob, welding knob and so on, Meanwhile. We also could make knob as customer need.

Our products are widely used in Security Industry of control the keyboard, move the camera and CCTV control systems, test equipment, measurement control, medical imaging control system, automatic machine control, video editing and production equipment, industrial and scientific use of instruments, wheelchair control, printing equipment, satellite, aviation, aerospace, marine, missiles, remote connector, operating robots, medical equipment, etc...

Our product are popular in America, Europe. Japan, Korea and so on. We are looking forward to even greater cooperation with overseas customers based on mutual benefits. Please feel free to contact us for more information.
